ATC-25

Automotive Blade Fuses ATC® Series Fast-Acting Time-Current Characteristic Curves - Average Melt 100 AMP RATING 3 4 5 7.5 10 15 20 25 30 40 10 Also available with open fuse indication in ratings from 3 to 40A. Contact factory for details 10 TIME IN SECONDS Catalog Symbol: ATC Fast-Acting Ratings: Volts: 32Vdc Amps: 1 to 40A Interrupting: 1000A Agency Approvals: UL Recognized, (3-40A) Guide JFHR2, File E56412 1 Ordering: Specify packaging and product code: Blank = five (5) fuses packed in a tin “BK” prefix = 2000 fuses packed in a carton .1 Product Number ATC-1 ATC-2 ATC-3 ATC-4 ATC-5 ATC-7 1/2 ATC-10 ATC-15 ATC-20 ATC-25 ATC-30 ATC-35 ATC-40 Fuse Body Color Code Black Gray Violet Pink Tan Brown Red Blue Yellow Clear Green Blue/Green Amber CURRENT IN AMPS 11.7 (0.460) 19.3 (0.760) 5.25 (0.207) Recommended Cooper Bussmann Fuse Holders* Part No. HHC HHF HHD HHG HHD-C HHR HHS ATC-FHID Description Yellow fuse holder Black fuse holder w/cover Black fuse holder Black fuse holder w/cover Cover Only Heavy duty, water resistant fuse holder Self-stripping fuse holder Illuminating fuse holder Fuse Range 1-20A 1-20A 1-30A 1-30A — 1-30A 1-20A 1-20A Lead Wire Size #16 #14 #12 #12 — #12 #18 to #14 #16 12.5 (0.492) 19.1 (0.752) 4.13 (0.163) 14.6 (0.575) 16.7 (0.657) 6.67 (0.263) *Also used in Cooper Bussmann 1A5600 Fuse Clips (0-20A) The only controlled copy of this Data Sheet is the electronic read-only version located on the Cooper Bussmann Network Drive. All other copies of this document are by definition uncontrolled. This bulletin is intended to clearly present comprehensive product data and provide technical information that will help the end user with design applications. Cooper Bussmann reserves the right, without notice, to change design or construction of any products and to discontinue or limit distribution of any products. Cooper Bussmann also reserves the right to change or update, without notice, any technical information contained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications. Life Support Policy: Cooper Bussmann does not authorize the use of any of its products for use in life support devices or systems without the express written approval of an officer of the Company. Life support systems are devices which support or sustain life, and whose failure to perform, when properly used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in significant injury to the user. © 2009 Cooper Bussmann St. Louis, MO 63178 www.cooperbussmann.com 0809 BU-SB09723 Page 1 of 1 Data Sheet 2009 1,000 100 Catalog Numbers (amps) 1 Dimensions: mm (in) .01
