5 x 20mm Fuses
S500 Series, Fast-Acting, Glass Tube
Description • Fast-acting, low breaking capacity • Optional axial leads available • 5 x 20mm physical size • Glass tube with silver-plated (32-125mA) and nickel-plated (160mA-10A) endcaps • Designed to IEC 60127-2 (160mA-10A)
Electrical Characteristics 1.5 In 2.1 In 2.75 In 4 In 10 In In min max min max min max max 32mA-125mA 60 min 30 min – – – – – 160mA-6.3A 60 min 30 min 50 ms 2 sec 10 ms 300 ms 20 ms 8A-10A 30 min 30 min 50 ms 2 sec 10 ms 400 ms 40 ms
Dimensions - mm
Drawing Not to Scale
5.54 (±0.20) 38.10 (±0.38)
Agency Information • cURus: File E19180, Guide JDYX2, JDYX8 • CSA Component Acceptance: File 1803366 • SEMKO Approval: File 414552 • VDE Approval: File 40014109 • BSI Approval: File KM55676 • IMQ Approval: File CA03.00097 • CCC Approval: File 2005010207155694 Ordering Specify product code • Insert packaging code prefix before part number. E.g. BK/S500-32-R
10 20 (±2.0) (±0.5)
21.10 (±0.81)
5.2 (±0.1/-0.2) 0.65 (REF)
38.10 (±0.38)
• Ratings above 6.3A have a 0.8mm diameter lead • With TR2 packaging code, lead wire length is 19.05mm Specify option code if desired • For axial leads, insert “V” between catalog series and amp rating. E.g. S500-V-100-R
Specifications
Voltage Interrupting Rating Typical DC Typical Maximum Agency Approvals Part Number Rating (amps) at Rated Cold Resistance Melting I2t Voltage Vac Voltage (50Hz) Vac (Ω)* AC† Drop (mV)‡ cURus CSA CCC BSI VDE SEMKO IMQ S500-32-R 250 35 40 0.000047 3200 S500-40-R 250 35 25 0.00011 2500 S500-50-R 250 35 17 0.00020 2400 S500-63-R 250 35 125 0.00057 2000 S500-80-R 250 35 5.0 0.0012 1200 S500-100-R 250 35 3.8 0.003 1100 S500-125-R 250 35 2.8 0.005 1000 S500-160-R 250 35 9.1 0.008 2000 X X X XX X X S500-200-R 250 35 6.8 0.016 1700 X X X XX X X S500-250-R 250 35 4.3 0.28 1400 X X X XX X X S500-315-R 250 35 3.1 0.58 1300 X X X XX X X S500-400-R 250 35 2.0 0.18 1100 X X X XX X X S500-500-R 250 35 0.26 0.18 220 X X X XX X X S500-630-R 250 35 0.20 0.35 220 X X X XX X X S500-800-R 250 35 0.14 0.67 190 X X X XX X X S500-1-R 250 35 0.125 0.60 200 X X X XX X X S500-1.25-R 250 35 0.096 0.84 200 X X X XX X X S500-1.6-R 250 35 0.066 1.6 190 X X X XX X X S500-2-R 250 35 0.043 4.2 150 X X X XX X X S500-2.5-R 250 35 0.034 6.1 150 X X X XX X X S500-3.15-R 250 35 0.025 13 130 X X X XX X X S500-4-R 250 40 0.021 22 130 X X X XX X X S500-5-R 250 50 0.014 42 120 X X X XX X X S500-6.3-R 250 63 0.010 69 120 X X X XX X X S500-8-R 250 80 0.010 N/A 120 X X XX X S500-10-R 250 100 0.008 N/A 120 X X XX X
* DC Cold Resistance (Measured at
