2211-12-421

2200 Series Reed Relays 2200 Series Reed Relays Ideally suited to the needs of Automated Test Equipment and RF requirements. The specification tables allow you to select the appropriate relay for your particular application. If your requirements differ, please consult your local representative or Coto’s Factory. 2200 Series Features Very small (0.17 in2), high reliability reed relays High Insulation Resistance - 1012 Ω available with some models High speed switching compared to electromechanical relays Hermetically sealed contacts for long life Epoxy coated steel shell provides magnetic shielding Optional Electrostatic Shield for reducing capacitive coupling Optional Coaxial Shield for 50 Ω impedance and switching of fast rise time digital pulses offered on some models Relay models 2200-2301, 2200-2302, are ATE industry standards. Specifically engineered for OEM designs and maintenance of existing production fixtures Dimensions in Inches (Millimeters) For .013 - .020 (0.33 - 0.5) dia. pin Recommended mounting hole: .040 ± .002 (1.0 ± 0.05) Bottom View Socket 2 Note: Model #’s 2200-2301 & 2200-2302 represent complete part numbers. * If Required, Order Coto Socket #0116-0100-0000 8 COTO TECHNOLOGY (USA) Tel: (401) 943-2686 / Fax (401) 942-0920 6 (Europe) Tel: +31-45-5439343 / Fax +31-45-5427216 2200 Series Reed Relays 3 Top View: Dot stamped on top of relay refers to pin #1 location Grid = .1"x.1" (2.54mm x 2.54mm) Notes: 1 Consult factory for life expectancy at other switching loads. 2 Model 2204, pin #7 is tied to optional electrostatic shield, pins #6 & #7 are tied to optional coaxial shield. 3 Consists of 56V Zener diode and 1N4148 diode in series, connected in parallel with coil. Environmental Ratings: Storage Temp: -35°C to +100°C; Operating Temp: -20°C to +85°C Solder Temp: 270°C max; 10 sec. max The operate and release voltage and the coil resistance are specified at 25°C. These values vary by approximately 0.4% / °C as the ambient temperature varies. Vibration: 20 G’s to 2000 Hz; Shock: 50 G’s 6 E-mail: sales@cotorelay.com For Most Recent Data, Consult the Coto Technology Website: www.cotorelay.com 9
