CT-64996F

Telecommunication Components ctparts.com Not shown at actual size. ISDN S-Interface 6 Pin, 7 Pin, 8 Pin DIP APPLICATIONS Through-hole single Meets the pulse waveform template of CCITT 1.430 when recommended transformer and chip pair is used Excellent longitudinal balance 2 K Vrms or higher voltage isolation RoHS Compliant. Electrical Specifications @ 25°C Compliant RoHS ORDERING INFO Single Transformers Part Number CT-64993F CT-64994F CT-64995F CT-64996F CT-64998F CT-64999F Ratio (± 2%) 1CT:1CT 1CT:1.8CS 1CT:2CT 1CT:2.5CS 1CS:2.5CS 1CT:2CT OCL Pri (mH min.) 22 22 22 22 22 22 Cw/w (pF Max.) 100 100 100 100 100 100 LL sec (µH Max.) 5 15 15 30 8-40 11 CD Pri (pF Max.) 42 140 80 150 110 180 DCR pri (Ω ± 25%) 2.4 2.5 2.3 2.5 2.5 2.4 DCR sec (Ω ± 25%) 2.4 4.2 4.0 5.8 5.8 4.4 Δ Idc (mA Max.) 1 1 1 1 1 1 Package/ Schematic SA SB SA SB SC SA SCHEMATICS 06.11.07 Technologies Manufacturer of Passive and Discrete Semiconductor Components 800-684-5322 Inside US 949-453-1811 Outside US Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved. CT Magnetics reserves the right to make improvements or change specifications without notice CENTRAL Telecommunication Components ctparts.com ISDN S-Interface 6 Pin, 7 Pin, 8 Pin DIP PHYSICAL DIMENSIONS (PACKAGE) 06.11.07 Technologies Manufacturer of Passive and Discrete Semiconductor Components 800-684-5322 Inside US 949-453-1811 Outside US Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved. CT Magnetics reserves the right to make improvements or change specifications without notice CENTRAL
