CT-65493F

Telecommunication Components ctparts.com Not shown at actual size. ISDN S- Interface 16 Pin DIP APPLICATIONS Through-hole, dual Meet the pulse waveform template of CCITT 1.430 when recommended transformer and chip pair is used Excellent longitudinal balance 2 K Vrms isolation RoHS Compliant. Compliant RoHS ORDERING INFO Part Number CT-65492F CT-65493F CT-65495F CT-65498F CT-65499F Coil A Ratio 1:1 1:1 1:2 1:2.5 1:2 Coil A Primary Pins 1-4 1-4 1-4 1-4 1-4 Coil A Secondary Pins 16-13 16-13 16-13 16-13 16-13 Coil B Ratio 1:2 1:1 1:2 1:2.5 1:2 Coil B Primary Pins 5-8 5-8 5-8 5-8 5-8 Coil B Secondary Pins 12-9 12-9 12-9 12-9 12-9 Refer to the equivalent single part number for electrical specifications. PHYSICAL DIMENSIONS (PACKAGE) 06.11.07 Technologies Manufacturer of Passive and Discrete Semiconductor Components 800-684-5322 Inside US 949-453-1811 Outside US Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved. CT Magnetics reserves the right to make improvements or change specifications without notice CENTRAL Telecommunication Components ctparts.com ISDN S-Interface 16 Pin DIP SCHEMATICS 06.11.07 Technologies Manufacturer of Passive and Discrete Semiconductor Components 800-684-5322 Inside US 949-453-1811 Outside US Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved. CT Magnetics reserves the right to make improvements or change specifications without notice CENTRAL
