CT-65612

Telecommunication Components ctparts.com Not shown at actual size. Digital Audio Data Transformer APPLICATIONS l For use with crystal semiconductor CS8401 & CS8402 l Fast rise time l Fast rise time compatible with standards l Through-hole and surface mount packages available Electrical Specifications @ 25°C Isolation: 2k Vrms Transmission Rates: 1 - 7 Mb/s Bandwidth: 100 kHz to 50 MHz 3dB typ. Return Loss: 100 kHz to 10 MHz 22dB min. Common Mode Rejection Ratio: 100 kHz 75dB min. 1 MHz 70dB min. 3 MHz 60dB min. 6 MHz 50dB min. 10MHz 40dB min. 30 MHz 25dB min. SCHEMATICS ORDERING INFO Part Number CT-65612 Turns Ratio (± 5%) 1:1 Primary Inductance (mH ± 20%) 2.5 Isolation LL (µH Max.) 0.50 Rise Time (n sec. Max.) 25 ET (V-µsec) 20 Voltage (Vrms) 2000 PHYSICAL DIMENSIONS 03.10.03 Technologies Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids 800-684-5322 Inside US 949-453-1811 Outside US Copyright © 2004 by CT Magnetics, DBA Central Technologies. All rights reserved. CT Magnetics reserves the right to make improvements or change specifications without notice CENTRAL
