Part No: CD-1206 Description: magnetic buzzer
Date: 8/21/2006 Unit: mm Page No: 1 of 5
Specifications
Rated voltage Operating voltage Mean current Coil resistance Sound output 5 Vo-p 4.0 - 8.0 Vo-p 40 mA max. 47 ±7 Ω Min. 85 (Typical 94) dBA Applying rated voltage, 2400 Hz square wave, ½ duty Distance at 10cm (A-weight free air). Applying rated voltage of 2400 Hz, square wave, ½ duty.
Rated frequency Operating tempurature Storage tempurature Dimensions Weight Material Terminal RoHS
2,400 Hz -30 ~ +70° C -40 ~ +85° C ø12 x H9 mm 1.6 g PPS (Black) SMD type (Au Plating) yes
See attached drawing
See attached drawing
Frequency Response Curve
Phone: 800.275.4899
Fax: 503.612.2381
www.cui.com
20050 SW 112th Ave.
Tualatin, OR 97062
Part No: CD-1206 Description: magnetic buzzer
Date: 8/21/2006 Unit: mm Page No: 2 of 5
Appearance Drawing
Tolerance: ±0.5
Measurement Method
Phone: 800.275.4899
Fax: 503.612.2381
www.cui.com
20050 SW 112th Ave.
Tualatin, OR 97062
Part No: CD-1206 Description: magnetic buzzer
Date: 8/21/2006 Unit: mm Page No: 3 of 5
Mechanical Characteristics
Item Solderability Soldering Heat Resistance Terminal Mechanical Strength Test Condition Lead terminals are immersed in a solder bath of +270 ±5°C for 3 ±1 seconds. Lead terminals are immersed in solder bath of +260 ±5°C for 3 ±1 seconds. Lead pads should be soldered onto the PC Board and then the force of 9.8 N (1.0 kg) should be applied behind the part for 10 seconds. The buzzer will be measured after applying a vibration amplitude of 1.5 mm with 10 to 55 Hz band of vibration frequency to each of the 3 perpendicular directions for 2 hours The part should be dropped from a height of 75 cm onto a 40 mm thick wooden board 3 times in 3 axis (X, Y, Z) for a total of 9 drops. Evaluation Standard 95% min. of lead terminals should be covered with fresh solder. No in interference in operation. No damage or cutting off.
Vibration
Drop Test
After the test, the part should meet specifications without any damage to the appearance and the SPL should be within ±10 dBA of the initial measurement.
Environment Test
Item High temp. test Low temp. test Thermal shock Test Condition The part will be subjected to +85°C for 96 hours. The part will be subjected to -40°C for 96 hours The part will be subjected to 10 cycles. One cycle will consist of: Evaluation Standard
Temp./Humidity cycle
The part shall be subjected to 10 cycles. One cycle should last 24 hours and will consist of:
After the test, the part should meet specifications without any damage to the appearance or performance except SPL. After 4 hours at 25°C, the SPL should be 80 dBA or more.
Phone: 800.275.4899
Fax: 503.612.2381
www.cui.com
20050 SW 112th Ave.
Tualatin, OR 97062
Part No: CD-1206 Description: magnetic buzzer
Date: 8/21/2006 Unit: mm Page No: 4 of 5
Reliability Tests
Item Operating (Life Test) Test Condition 1. Continuous life test: The part will be subjected to 72 hours at 55°C with 5 V, 2400 Hz applied. 2. Intermittent life test: A duty cycle of 1 minute on, 1 minute off, a minimum of 10,000 times at room temp. (+25 ±10°C) with 5 V, 2400 Hz applied. Evaluation Standard After the test, the part should meet specifications without any damage to the appearance or performance except SPL. After 4 hours at 25°C, the SPL should be 80 dBA or more.
Test Conditions
Standard Test Condition Judgement Test Condition a) Tempurature: +5 ~ +35°C a) Tempurature: +25±2°C b) Humidity: 45 - 85% b) Humidity: 60 - 70% c) Pressure: 860 - 1060 mbar c) Pressure: 860 - 1060 mbar
Recommended Temperature Profile for Reflow Oven
Recommended Land Pattern
Phone: 800.275.4899
Fax: 503.612.2381
www.cui.com
20050 SW 112th Ave.
Tualatin, OR 97062
Part No: CD-1206 Description: magnetic buzzer
Date: 8/21/2006 Unit: mm Page No: 5 of 5
Packaging
