VF-S150-18A-CF

1/5 VF-S150-XXA Series Switching Power Supply Rev. 7-2007 Features · · · · · · · · · AC input range auto-selectable Power factor correction Remote on/off Power good signal Short circuit protection Over load protection Over voltage protection Over temperature protection Providing Peak Power 600W within 500uS duty · Approved to UL, CUL, TUV, CE with CB scheme · High power density: 6.25watts.cu in. E222889 Model VF-S150-03A-CF VF-S150-05A-CF VF-S150-12A-CF VF-S150-18A-CF VF-S150-24A-CF VF-S150-48A-CF Preset Voltage 3.3V 5V 12V 18V 24V 48V Output Current Output 1, 2, 3 3 5 12 17 24 35 4V 6V 16 V 23 V 30 V 56 V Minimum 0A 0A 0A 0A 0A 0A Maximum 30 A 30 A 12.5 A 8.82 A 6.25 A 4.28 A Max. Power 4 99 W 150 W 150 W 150 W 150 W 150 W Ripple & Noise 5, 6 Regulation 5 +/- 1% +/- 1% +/- 1% +/- 1% +/- 1% +/- 1% (Vpp) 50 mV 50 mV +/- 1% +/- 1% +/- 1% +/- 1% Notes: 1 Customer must specify output voltage on PO. 2 Output is fully isolated. 3 Output voltage is measured at output power connector. 4 Provides peak power of 600 W within 500 µS for all models. For longer duty duration please contact us. 5 1% minimum load is required to maintain the ripple and regulation. 6 Ripple and noise is measured from 10 KHz to 20 MHz at output terminals with a 0.1 µF ceramic capacitor and a 22 µF electrolytic capacitor in parallel. V-Infinity, LLC, 20050 SW 112th Ave., Tualatin, OR 97062 www.v-infinity.com 1-866-372-1258 2/5 VF-S150-XXA Series Switching Power Supply Rev. 7-2007 Input Parameter Input Frequency Input Voltage Input Current Inrush Current Power Factor Conditions/Description 90-132 / 180-264 auto-selectable At 115 VAC At 230 VAC Peak measured at 230 VAC at full load, cold start Peak measured at 115 VAC at full load, cold start Active power factor correction meets EN61000-3-2 class A Min 47 90 Nom Max 63 264 4 2 70 35 Units Hz VAC A A A A Output Parameter Transient response Conditions/Description Min Nom Max Output voltage returns to within 1% in less than 2.5 mS for a 50% load change. Peak t ransient does not exceed 5%. Turn-on and turn-off overshoot shall not exceed 5 % over nominal voltage. Measured at 230 V and full load 3.3 model: 70% 5 V model: 75% 12 V model: 80% Minimum for all other models: 83% At 120 VAC 1 At 120 VAC and 80% of rated maximim load 20 Adjustable with built-in trim pot. +/- 5% Designated as RMSW on the CN1. Requires a low signal to inhibit the output. When green (LED1) is on the power supply is operating normally. Designated as PG on the CN1. This signal goes high 100-500 mS after the output reaches regulation. I t goes low at least 1 mS before loss of regulation. Units Overshoot Efficiency Turn on delay Hold up time Adjustability R emote Inhibit LED display Power Good second mS Protection Circuit Parameter Input Fuse Overload Short circuit Output Over-voltage Conditions/Description Built-in ac fuse. A blown fuse usually indicates permanent damage to the power supply serviceable by factory only. Current limiting starts at 110-140% of the rated output current in foldback mode and recovers automatically. Short circuit can be continuous. Recovers automatically upon removal of short. Output is protected agaist overvoltage. Unit shuts down and latches when voltage at output terminals exceeds 130%. AC input needs to be r eset to restart the power supply. Power supply shuts down when temperature is in excess of 85 ºC. Auto recovery. Over temp. V-Infinity, LLC, 20050 SW 112th Ave., Tualatin, OR 97062 www.v-infinity.com 1-866-372-1258 3/5 VF-S150-XXA Series Switching Power Supply Rev. 7-2007 General and Safety Parameter Operating temp. Storage temp. Operating humid. Storage humid. EMI Safety Leakage Current Switching Frequency Vibration Isolation Voltage (HI-POT) Non-condensing Non-condensing Conditions/Description Derates linearly from 100% load at 50 ºC to 50% load at 70 ºC. -20 5% 5% 85 90% 95% ºC RH RH Min 0 Nom Max 70 Units ºC CISPR 22 / EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN55024 CE Marked (LVD) UL60950(E222889), CSA C22.2 No. 60950, TUV EN60950 and CB at 240 VAC 25K Acceleration +/- 7.35 M/(SxS), on X, Y and Z Axis 5 Applied for 3 seconds Primary to secondary: 3000 Primary to transformer core: 1500 Primary to earth ground: 1500 Allowable resistance measured when 25 A current is applied from the ground pin of the three prong plug t o the farthest earthed connection point. Standard warranty length According to MIL-HDBK-217 at 30 ºC 100,000 Full load, at 45 +/- 5 ºC, 230 VAC. Convection, with 12VDC/300mA available to drive external fan 1.5 50 mA Hz Hz VAC VAC VAC Ω Grounding Test 0.1 Warranty MTBF Burn-in Cooling 2 1 years hours hours Mechanical P arameter Weight Enclosure Conditions/Description 5.0(L) x 3.2(W) x 1.5(H) Min Nom Max 400 Units grams inches I nput Connector - (CN3) Conditions/Description Molex Part No. 26-48-1201 or similar (5 pin). Suggested mating plug: Molex Part No. 09-91-0500 or equivalent (5 pin, 3 used) AC Input (Option 2) Howder Terminal block Part No. HD-601-3P (3 pin, M3 Screw) 6.35mm spacing Suggested mating connector: M olex 2478, 2578, 8818 or similar Note : Input connector needs to be specified on the PO. P arameter AC input (Option 1) V-Infinity, LLC, 20050 SW 112th Ave., Tualatin, OR 97062 www.v-infinity.com 1-866-372-1258 4/5 VF-S150-XXA Series Switching Power Supply Rev. 7-2007 Output Connector - (CN2) Parameter Output (Option 1) Conditions/Description Molex Part No. 26-48-1201 or similar.(6 pin) Output pin assignment, VO+ (Pins 1-3), VO- (Pins 4-6) Suggested mating connector: M olex Part No. 09-91-0600, contact:08-50-0106 or similar. Output (Option 2) Howder Terminal block Part No. HD-121-6P (6 pin, M3.5 Screw) 6.5mm spacing Output pin assignment, VO+ (Pins 1-3), VO- (Pins 4-6) Note: Suggested mating connector: H owder HD-601-4P or similar. Output connector needs to be specified on the PO. Logic Connector - (CN1) Parameter Logic Pin Assignments: Conditions/Description JS B7B-XH-A Suggested mating connector: J ST XHP-3 or equivalent , Contact: SXH-001T-P0.6. 1. P.G - Power good 2. RMSW - Remote on/off 3. RTN - Return JST B2B-XH-A Suggested mating connector: J ST XHP-2 or equivalent, Contact: SXH-001T-P0.6. Fan V-Infinity, LLC, 20050 SW 112th Ave., Tualatin, OR 97062 www.v-infinity.com 1-866-372-1258 5/5 VF-S150-XXA Series Switching Power Supply Rev. 7-2007 B B B With optional cover V-Infinity, LLC, 20050 SW 112th Ave., Tualatin, OR 97062 www.v-infinity.com 1-866-372-1258
