Card Edge Connectors The card edge connector provides a fast means for connecting/disconnecting single, double-sided or multilayer printed circuit boards. Contact force consistency is obtained through the use of a long cantilevered contact having a minimum deflection angle and an extended self-cleaning, wiping action. These contacts ensure positive connection to the board, even when pad surfaces are irregular. Good contact pressure is maintained with minimum wear on PC board pads, even in hostile environments, and after numerous insertions and withdrawals or shock and vibration. • Insulator protects contacts from possible damage when mated with PC board. • Polarizing key slots allow positive polarization without loss of a contact position. • Contact and cover design provides for reuse. Connector can be reterminated easily and reliably to a new section of cable. • Sturdy cover posts provide protection against cable pulls of 25 lb or more. • Patented Torq-Tite™ contact keeps conductor under constant tension. Assures a mechanically and electrically, sound, gas-tight connection. • Recessed slot provide means for non-destructive removal of cover. 26 • 130 James Way, Southampton, PA 18966 - 3838 • Telephone: (215) 355-7080 • Fax: (215) 355-1088 • www.cwind.com Con tact • Lead-in on contact helps align the conductor with the IDC slot. • Patented, offset tines produce Torq-Tite™ termination for added reliability. • Long cantilever produces less angular deflection as PC board is inserted. • Contact with the PC board is made near the face of the connector for increased wiping action. • Unsupported contact tail allows for self-adjustment to compensate for PC board irregularities. Car d Edge Con n ector Featur es • 10, 20, 26, 34, 40, and 50 contact versions. • Compatible with various PC board thicknesses, from .032 in. to .070 in. thick. • Standard gold-plated phosphor bronze contacts; tin-lead plated contacts optional. • Can be daisy-chained or applied in cable end terminations. • Factory pre-assembled cover minimizes assembly time. • Available with or without mounting flanges. • Dependable long cantilever contact design maintains consistent pressure even after repeated matings with PC boards. Insures a long insertion/withdrawal cycle life and a good self-cleaning wipe on each PC board pad. • Self-adjusting contact compensates for variations in PC board thickness. • Closed entry protection prevents possible damage caused by PC board irregularities. Card Edge Connectors Str ain Relief Strain relief is an integral part of CW Card Edge connector. A strain relief lip is molded into the connector body. Upon installation of the cover, this lip causes a strain relief bend in the cable that prevents forces applied to the cable from being transferred to the IDC termination. Polar ization Positive polarization is available on all CW card edge connectors. A polarizing key, inserted into a V-slot located between any two contacts, fits into a corresponding .037 in. slot cut into the PC board. This technique not only provides positive polarization without loss of a contact position, but also helps ensure precise alignment of the contacts to the PC board’s pads. Assembly Assembling these connectors is both fast and easy using only a simple bench press. The connector body is designed to orient the cable to the contact tines, and the factory preassembled cover permits termination of all conductors in one step–simply apply opposing parallel forces on the connector cover and base. • 130 James Way, Southampton, PA 18966 - 3838 • Telephone: (215) 355-7080 • Fax: (215) 355-1088 • www.cwind.com 27 Card Edge Connectors En gin eer in g Dimen sion s Dimen sion s .128 DIA. 2 PLACES (3.25) SPACES @ .100 = A (2.54) 1 1 9 G 10 E C 2 ± .010 ( ± 0.25) C 1 ± .010 ( ± 0.25) .41 (10.4) .51 (13.0) B E C1 VARIATION WITH NO FLANGES .074 (1.88) .18 Point of (4.6) Board contact. .71 (18.0) .83 (21.1) BASE COVER Resting place of P.C. board fully inserted. D Closed Position VARIATION WITH MOUNTING FLANGES POLARIZING KEY CWN - KEY 2 Open Position .09 (2.29) RECOMMENDED P.C. BOARD DIMENSIONS .40 (10.2) .04 x 45º (1.0) Chamfer .39 (9.9) .055 (1.40) P.C. Pad Typ. PAD CENTERS .100± .003 = A (2.54 ± .08) .03 (0.8) .037 (.94) .10 (2.5) F Polarizing Key Slot Located Centrally Between any Two Adjacent P.C. Pads. CONNECTOR DIMENSIONS NO. CONTS. A .400 (10.16) .900 (22.86) 1.200 (30.48) 1.600 (40.64) 1.900 (48.26) 2.400 (60.96) B 1.300 (33.02) 1.800 (45.72) 2.100 (53.34) 2.500 (63.50) 2.800 (71.12) 3.400 (86.36) C 1 C 2 D .520 (13.21) 1.020 (25.91) 1.320 (33.53) 1.720 (43.69) 2.020 (51.31) 2.520 (64.01) E .604 (15.34) 1.104 (28.04) 1.404 (35.66) 1.804 (45.82) 2.104 (53.44) 2.604 (66.14) F .596 (15.14) 1.096 (27.84) 1.396 (35.46) 1.796 (45.62) 2.096 (53.24) 2.596 (65.94) G .43 (10.9) .43 (10.9) .43 (10.9) .43 (10.9) .43 (10.9) .44 (11.2) 10 20 26 34 40 50 .976 (24.79) 1.476 (37.49) 1.776 (45.11) 2.176 (55.27) 2.476 (62.89) 2.976 (75.59) 1.500 (38.10) 2.000 (50.80) 2.300 (58.42) 2.700 (68.58) 3.000 (76.20) 3.900 (99.06) 28 • 130 James Way, Southampton, PA 18966 - 3838 • Telephone: (215) 355-7080 • Fax: (215) 355-1088 • www.cwind.com 10 2 2 9 Card Edge Connectors Specification s an d Or der in g In for mation Specification s • Contacts: phosphor bronze standard. • Contact Plating: 30µ in. gold (in mating area) over 50µ in. nickel, standard; 10µ in. gold (in mating area) over 50µ in. nickel, optional; 50µ in. gold (in mating area) over 50µ in. nickel, optional; 100µ in. tin-lead optional • Insulator Material: UL 94V-0 flame - retardant thermoplastic • Color: blue • Operating temperature: -55º to +125ºC • Current Rating: 1A(maximum) per contact • Dielectric Withstand Voltage: greater than 500 Vdc at sea level • Insulation Resistance: greater than 5 x 109 ohms • Cover pull-off force 8 oz/contact min. (force along contacts’ primary axes) How to Or der Car d Edge Con n ector s CWR-XXX-XX-00XX Type of Connector 170=Card edge connector without mounting ears 171=Card edge connector with mounting ears Plating 0021=30µ in. gold (in mating area) over 50µ in. nickel (standard) 0000=10µ in. gold (in mating area) over 50µ in. nickel 0055=50µ in. gold (in mating area) over 50µ in. nickel 0003=100µ in. tin-lead Number of Contacts (10, 20, 26, 34, 40, or 50) How to Or der Car d Edge Cable Assemblies Cable assemblies with two card edge connectors on a prescribed length of color-coded cable are available with the connectors oriented per drawing 27-1. (#1 contacts oriented to brown conductor.) For other lengths, orientations, numbers or combinations of connectors,contact your local value - added distributor. L DRAWING 27-1 CA-XX-9X0X Number of Conductors (10, 20, 26, 34, 40, 50) Final assembly length “L” 1=3”+1/8” 2=6”+1/8” 3=12”+1/4” 4=24”+1/4” 5=48”+1/4” Type of Connector 4=card edge connectors without mounting ears. CWR-170-XX-0021 (See drawing 27-1) 5=card edge connectors with mounting ears CWR-171-XX-0021 (See drawing 27-1) • 130 James Way, Southampton, PA 18966 - 3838 • Telephone: (215) 355-7080 • Fax: (215) 355-1088 • www.cwind.com 29
