ES-4B-T3CK-A5S

DB LECTRO Inc. ES40-T Sealed Sub-Miniature Toggle Switches FEATURE 1. Sealed construction - internal actuator o-ring and epoxy terminal seal standard 2. Carry the IP67 approvals 3. The ESD protection available - Anti-static plastic actuator -9000 V DC static resistance between toggle and terminal. CONTACT RATING:R- 0.4 VA max @ 20 V AC or DC ELECTRICAL LIFE:30,000 make-and-break cycles at full load CONTACT RESISTANCE: 20 m max. initial @2-4 VDC,100 mA INSULATION RESISTANCE: 1,000 M min. DIELECTRIC STRENGTH: 1,500 V RMS @ sea level. ESD Resistant Option : P2 insulating actuator only:9,000 VDC min. @ sea level,actuator to terminals. DEGREE OF PROTECTION : IP67 OPERATING TEMPERATURE: -30 C to 85 C SPECIFICATIONS MATERIALS IP 67 protection degree CASE and BUSHING - glass filled nylon 4/6,flame retardant heat stabilized (UL94V-0) Actuator - Brass , chrome plated,internal o-ring seal standard with all actuators P2 / the anti-static actuator: Nylon 6/6,black standard(UL 94V-0) CONTACT AND TERMINAL - Brass , silver plated SWITCH SUPPORT - Brass , tin-lead TERMINAL SEAL - Epoxy How do you build the switches you need!! The ES-4 / ES-5 , please see the (A) ; (A) ES 4 P2 Actuator T1 T2 T3 T4 T5 Std. Std. 10.57 6.10 8.13 13.97 3.5 The ES-6/ES-7/ES-8/ES-9, please see the (B) A5 Contact Material Q R G K silver plated gold plated gold over silver gold / tin-lead Vertical support Bracket (none) A5 straight type A5S (std.) snap-in type C R Switch Funtction ES-4 ES-4B ES-4A ES-4H ES-4I ES-5 ES-5B ES-5A ES-5H ES-5I SP SP SP SP SP DP DP DP DP DP on-none-on on-none-(on) on-off-on (on)-off-(on) on-off-(on) on-none-on on-none-(on) on-off-on (on)-off-(on) on-off-(on) Termination C (std) P.C ESD protection actuator P2 (std - black) 6.10 P21 (white) 6.10 (B) Horizon Right Angle ES-6 ES-6B ES-6A ES-6H ES-6I ES-7 ES-7B ES-7A ES-7H ES-7I ES 6 T2 Switches Function SP SP SP SP SP DP DP DP DP DP on-none-on on-none-(on) on-off-on (on)-off-(on) on-off-(on) on-none-on on-none-(on) on-off-on (on)-off-(on) on-off-(on) R S Contact Material Q R G K silver plated gold plated gold over silver gold / tin-lead Support Bracket type S (std.) Snap-in type (none) straight type Vertical Right Angle ES-8 ES-8B ES-8A ES-8H ES-8I ES-9 ES-9B ES-9A ES-9H ES-9I Actuator T1 T2 T3 T4 T5 Std. 10.57 6.10 8.13 13.97 3.5 ESD protection actuator P2 (std - black) 6.10 P21 (white) 6.10 DB LECTRO Inc. 3600 boul. Matte suite i Brossard Qc J4Y-2Z2 tel:(450)-444-1424 fax:(450)-444-4714 DB LECTRO Inc. SPDT ES40-T Sealed Sub-Miniature Toggle Switches EPOXY SEAL 25 Model No. ES-4 ES-4A ES-4B ES-4H ES-4I Switching position POS 3 .180 DIA. 4.57 POS 2 POS 1 ON ON ON (ON) ON 2-3 none OFF None OFF OFF open ON ON (ON) (ON) (ON) 2-1 .100 DIA. 2.54 ø 3 2 1 .177 4.50 .400 10.16 .527 13.39 .020 TYP. 0.51 .320 8.13 .100 TYP. 2.54 .130 3.30 .200 5.08 3 2 1 .030 TYP. 0.76 TERM. WIDTH A 22 2 Comm 1 3 Term. Comm. ES-4- T1CR Switching position 25 DPDT Model No. ES-5 ES-5A ES-5B ES-5H ES-5I EPOXY SEAL .100 DIA. 2.54 ø 6 5 4 .177 4.50 .400 10.16 .527 13.39 .130 3.30 .100 TYP. 2.54 .020 TYP. 0.51 6 .320 8.13 5 4 .360 9.14 .200 5.08 3 2 1 .030 TYP. 0.76 TERM. WIDTH ON ON ON (ON) ON none OFF None OFF OFF ON ON (ON) (ON) (ON) .180 DIA. 4.57 POS 3 POS 2 POS 1 2 Comm 1 3 4 5 Comm 6 Term. Comm. 2-3,5-6 open 2-1,5-4 ES-5- T1CR .240 6.10 SPDT Model No. ES-6 ES-6A ES-6B ES-6H ES-6I Switching position .162 4.11 EPOXY SEAL .320 8.13 ON ON ON (ON) ON 2-3 none OFF None OFF OFF open ON ON (ON) (ON) (ON) 2-1 straight type .240 6.10 .200 5.08 .030 TYP. 0.76 .015 0.38 .165 4.19 .200 5.08 .030 0.76 .020 0.51 .200 5.08 1 2 3 .020 TYP. 0.51 .200 5.08 .130 3.30 2 Comm 1 3 Term. Comm. ES-6 - T2R-S .162 4.11 EPOXY SEAL .320 8.13 45 .020 0.51 .360 9.14 6 DPDT Model No. ES-7 ES-7A ES-7B ES-7H ES-7I Switching position ON ON ON (ON) ON none OFF None OFF OFF ON ON (ON) (ON) (ON) .200 5.08 .030 TYP. 0.76 1 .015 0.38 .165 4.19 .130 3.30 .030 0.76 .100 2.54 .200 5.08 23 .020 TYP. 0.51 .200 5.08 2 Comm 1 3 4 5 Comm 6 Term. Comm. 2-3,5-6 open 2-1,5-4 straight type .230 5.84 .240 6.10 POS 3 ES-7- T2R-S EPOXY SEAL SPDT Model No. ES-8 ES-8A ES-8B ES-8H ES-8I Switching position ON ON ON (ON) ON 2-3 none OFF None OFF OFF open ON ON (ON) (ON) (ON) 2-1 .030 0.76 POS 2 POS 1 .162 4.11 .015 0.38 .165 4.19 straight type .200 5.08 1 2 .020 0.51 .100 2.54 3 .130 3.30 .320 8.13 3 2 1 .530 13.46 2 Comm 1 3 Term. Comm. ES-8 - T2R-S .398 10.11 .240 6.10 POS 3 EPOXY SEAL .030 TYP. 0.76 DPDT Model No. ES-9 ES-9A ES-9B ES-9H ES-9I Switching position ON ON ON (ON) ON none OFF None OFF OFF ON ON (ON) (ON) (ON) .200 TYP 5.08 POS 2 POS 1 .162 4.11 .015 0.38 .165 4.19 straight type .200 5.08 5 .020 0.51 .100 2.54 6 .130 3.30 .320 8.13 6 5 4 3 2 1 .530 13.46 2 Comm 1 3 4 5 Comm 6 Term. Comm. 2-3,5-6 open 2-1,5-4 4 ES-9- T2R-S .030 TYP. 0.76 DB LECTRO Inc. 3600 boul. Matte suite i Brossard Qc J4Y-2Z2 tel:(450)-444-1424 fax:(450)-444-4714 DB LECTRO Inc. ES40-T A 23 T1 .100 DIA ø2.52 Sealed Sub-Miniature Toggle Switches Actuator Option T2 .100 DIA ø2.52 T3 .100 DIA ø2.52 T4 .100 DIA ø2.52 T5 .100 DIA 2.52ø .40 10.16 .240 6.10 .320 8.13 .550 13.97 P2 PLASTIC TOGGLE (NEW) .100 DIA ø2.52 .140 3.50 .240 6.10 Meterial Nylon 4/6 (UL 94V-0),black std. Static resistance:9,000V DC min. @sea level , actuator to terminals code P2 P21 description black(std.) white Bushing dimension SP .177 4.50 Terminal dimension DP .130 3.30 EPOXY SEAL .180 DIA 4.57ø .020 THK. 0.76 .020 THK. 0.51 .130 3.30 .200 5.08 EPOXY SEAL .030 0.76 P.C.B Mounting Dimension ES-4 .043 DIA ø1.09 .200 5.08 .100 2.54 ES-6 .200 5.08 .043 DIA ø1.09 .200 5.08 .100 2.54 ES-8 .200 5.08 .100 2.54 .043 DIA ø1 .09 ES-5 .100 2.54 .200 5.08 .043 DIA ø1 .09 ES-7 .200 5.08 .100 2.54 .200 5.08 .100 2.54 .100 2.54 ES-9 .200 5.08 .100 2.54 .200 5.08 .043 DIA ø1.09 .043 DIA ø1.09 SPDT DPDT CONTACT MATERIAL OPTIONS CODE Q R G K CONTACT MATERIAL Silver plated TERMINAL MATERIAL Silver plated RATING 3 A @ 120V AC or 28 V DC; 1.5 A @ 250 VAC Gold plated over nickel plated Gold plated over nickel plated 0.4VA MAX @ 20 V AC or DC MAX Gold plated over silver plated Gold plated over silver plated 0.4 VA MAX @ 20 V AC or DC MAX or 3 A @ 120V AC or 28 V DC; 1.5 A @ 250 VAC Gold plated over nickel plated Tin-lead over nickel plated 0.4VA MAX @ 20 V AC or DC MAX The "K" option is only for some special item. Please inquiry first when you need the "K" option VERTICAL SUPPORT BRACKET OPTION A5 .363 9.22 .240 6.10 .163 4.13 .240 6.10 .163 4.13 .363 9.21 .130 3.29 .203 5.16 .400 10.16 .043 DIA ø1.09 .100 2.54 .400 10.16 .100 2.54 .043 ø1.09 .200 5.08 .382 9.71 .135 3.43 .030 0.76 .200 5.08 .400 10.16 1 2 3 1 2 3 .016 0.41 .016 0.41 .100 2.54 .020 0.51 .400 10.16 .100 2.54 .020 0.51 A5S (std.) snap-in type A5 straight type ES-4-T2-CQ-A5S ES-5-T2-CQ-A5S DB LECTRO Inc. 3600 boul. Matte suite i Brossard Qc J4Y-2Z2 tel:(450)-444-1424 fax:(450)-444-4714 DB LECTRO Inc. FEATURE ES40-T Sealed SMT Sub-Miniature Toggle Switches A 1. Sealed construction - internal actuator o-ring and epoxy terminal seal standard 2. Carry the IP67 approvals 3. The ESD protection available - Anti-static plastic actuator -9000 V DC static resistance between toggle and terminal. 24 4. Surface mounting (SMT) 5. Tape and Reel package SPECIFICATIONS CONTACT RATING:R- 0.4 VA max @ 20 V AC or DC DCELECTRICAL LIFE:30,000 make-and-break cycles at full load CONTACT RESISTANCE: 20 m max. initial @2-4 VDC,100 mA INSULATION RESISTANCE: 1,000 M min. DIELECTRIC STRENGTH: 1,500 V RMS @ sea level. ESD Resistant Option : P2 insulating actuator only:9,000 VDC min. @ sea level,actuator to terminals. DEGREE OF PROTECTION : IP67 OPERATING TEMPERATURE: -30 C to 85 C CASE and BUSHING - glass filled nylon 4/6,flame retardant heat stabilized (UL94V-0 ) Actuator - Brass , chrome plated,internal o-ring seal standard with all actuators P2 / the anti-static actuator: Nylon 4/6,black standard(UL 94V-0) CONTACT AND TERMINAL - Copper alloy , silver plated SWITCH SUPPORT - Brass , tin-lead TERMINAL SEAL - Epoxy MATERIALS IP67 How do you build the switches you need!! ES Switches Function ES-3 ES-3B ES-3A ES-3H ES-3I SP SP SP SP SP on-none-on on-none-(on) on-off-on (on)-off-(on) on-off-(on) T1 T2 T3 T4 T5 3 T2 Actuator Std. 10.57 6.10 8.13 13.97 3.5 N R Contact Material Q R G K silver plated gold plated gold over silver gold / tin-lead Terminal (none) std N backward M backward ESD protection actuator P2 (std - black) 6.10 P21 (white) 6.10 the Contact K only apply to the terminal N/ M DB LECTRO Inc. 3600 boul. Matte suite i Brossard Qc J4Y-2Z2 tel:(450)-444-1424 fax:(450)-444-4714 DB LECTRO Inc. A 25 ES40-T Sealed SMT Sub-Miniature Toggle Switches .240 6.10 Model No. ES-3 ES-3A ES-3B ES-3H ES-3I 2 Comm 1 3 Term. Comm. Switching position .320 8.13 .162 4.11 EPOXY SEAL .020 0.51 .320 8.13 ON ON ON (ON) ON 2-3 none OFF None OFF OFF open ON ON (ON) (ON) (ON) 2-1 .410 10.40 .100 2.52 .030 0.76 .200 5.08 .100 2.54 .020 0.62 ES-3 - T2R The N termial type .320 8.13 .240 6.10 .162 4.11 EPOXY SEAL Model No. ES-3 ES-3A ES-3B ES-3H ES-3I 2 Comm 1 3 Term. Comm. Switching position .200 5.08 .019 0.50 .083 2.10 ON ON ON (ON) ON 2-3 none OFF None OFF OFF open ON ON (ON) (ON) (ON) 2-1 .150 3.81 .100 2.54 .039 1.00 .100 2.54 without positioning pings ES-3-T2NK ES-3 - T2 MK Actuator Option P2 PLASTIC TOGGLE (NEW) T1 T2 T3 T4 .100 DIA 2.52ø .100 DIA ø2.52 .40 10.16 .240 6.10 .320 8.13 .100 DIA ø2.52 .550 13.97 .100 DIA 2.52ø T5 .100 DIA ø2.52 .240 6.10 .100 DIA ø2.52 code P2 P21 description black(std.) white .140 3.50 Meterial Nylon 4/6 (UL 94V-0),black std. Static resistance:9,000V DC min. @sea level , actuator to terminals THE P.C.B MOUNTING .140 3.56 .080 2.03 .039 dia 1.00ø .313 7.96 .150 3.81 .271 6.90 .271 6.90 .090 7.62 .300 2.29 .080 2.03 .070 1.80 .082 2.10 .313 7.96 .070 1.80 .082 2.10 .150 3.81 .040 1.02 .100 2.54 .031 0.80 .100 2.54 .031 0.80 ES-3-TX-R ES-3-TX-MK ES-3-TX-NK CONTACT MATERIAL OPTIONS CODE Q R G K CONTACT MATERIAL Silver plated TERMINAL MATERIAL Silver plated RATING 3 A @ 120V AC or 28 V DC; 1.5 A @ 250 VAC Gold plated over nickel plated Gold plated over nickel plated 0.4VA MAX @ 20 V AC or DC MAX Gold plated over silver plated Gold plated over silver plated 0.4 VA MAX @ 20 V AC or DC MAX or 3 A @ 120V AC or 28 V DC; 1.5 A @ 250 VAC Gold plated over nickel plated Tin-lead over nickel plated 0.4VA MAX @ 20 V AC or DC MAX THE K option is only for the terminal "N/ M" DB LECTRO Inc. 3600 boul. Matte suite i Brossard Qc J4Y-2Z2 tel:(450)-444-1424 fax:(450)-444-4714
