RI-09

P.C.B. LAYOUT RI & RIR CONSTRUCTION RI series 1. 2. 3. 4. 5. 6. RIR series RI series (raised actuator) and RIR series (recessed actuator) available for different purposes. Splay terminals allow for automatic insertion by IC insertion machine. Straight terminals are available for manual insertion. Low contact resistance, and self-clean on contact area. Gold plated electrical contact and terminal plating by gold gives excellent results when soldering. All materials are UL94V-0 grade fire retardant plastics. ITEM Description Materials 1 2 3 4 5 Actuator Cover Base Contact Terminal UL94V-0 Nylon UL94V-0 Nylon UL94V-0 Nylon Treatment Molded white Molded black Molded black Gold plated at contact area and gold plating at terminal CIRCUIT DIAGRAM Beryllium Copper Gold plated at contact area Brass DB LECTRO Inc. 3755 Place Java, Suite 140, Brossard, Québec, J4Y 0E4, Canada - T: 1-450-444-1424 / F: 1-450-444-4714 / www.dblectro.com MODEL PROD NO. RI/RIR-01 RI/RIR-02 RI/RIR-03 RI/RIR-04 RI/RIR-05 RI/RIR-06 RI/RIR-07 RI/RIR-08 RI/RIR-09 RI/RIR-10 RI/RIR-12 HOW TO ORDER NO. OF POS 01 02 03 04 05 06 07 08 09 10 12 DIM A 3.48 6.02 8.56 11.1 13.64 16.18 18.72 21.26 23.8 26.34 31.42 0.137 0.237 0.337 0.437 0.537 0.637 0.737 0.837 0.937 1.037 1.237 SPECIFICATION ELECTRICAL Electrical life: 2000 operation cycles per switch 24VDC, 25mA. Non-Switching Rating: 100mA, 50 VDC Switching Rating: 25mA, 24VCD. Contact resistance: (a) 50mΩ max. at initial (b) 100mΩ max. after life test. Insulation resistance: 100MΩ min. (at 500VDC) Dielectric Strength: 500VAC/1 minute. Capacitance: 5pF max. Circuit: Single pole single throw MECHANICAL Mechanical life: 2000 operations per cycle switch Operation Force: 600gf max. Stroke: 0.9mm Operation Temp: -25° C to +70° C Storage Temp: -40° C to +85° C Vibration Test: MIL-STD-202F METHOD 201A Frequency: 10-55-10Hz/1 min Directions: X, Y, Z, three mutually perpendicular directions. Time: 2 hours each direction. High reliability. Shock Test: MIL-STD-202F METHOD 213B. CONDITION A GRAVITY: 50G (peak value), 11 m/sec. Direction and times: 6 sides and three times in each direction. High reliability. SOLDERING AND CLEANING PROCESSES For best results, please follow these recommendations: Keep all switch contacts in their "OFF" position for all operations. WAVE SOLDERING: Recommended solder temperature at 500 F (260° C) max. 5 seconds. HAND SOLDERING: Use a soldering iron of 30 watts, controlled at 608 F(320° C) approximately 2 seconds while applying solder. CLEANING PROCESS: Flux clean using force rinse, high agitation or triple bath cleaning method. Freon TF or TE give excellent results. When vapor methods are used, do not subject the switch to solvents at temperatures above 125 F (51° C). TERMINAL TYPE Example: RI-08G-S is a Machine Insertable Type Dip Switch, Raised Actuator 8 position, splay terminal. PACKING All DIP switches are shipped in standard IC tubes with all poles in "OFF" position. DB LECTRO Inc. 3755 Place Java, Suite 140, Brossard, Québec, J4Y 0E4, Canada - T: 1-450-444-1424 / F: 1-450-444-4714 / www.dblectro.com
