RI-12

厂商：
DBLECTRO
封装：
描述：
RI-12 - Machine Inertable Type Dip Switch - DB Lectro Inc

数据手册：

下载RI-12.pdf

立即购买

详情介绍
数据手册
价格&库存

RI-12 数据手册

P.C.B. LAYOUT RI & RIR CONSTRUCTION RI series 1. 2. 3. 4. 5. 6. RIR series RI series (raised actuator) and RIR series (recessed actuator) available for different purposes. Splay terminals allow for automatic insertion by IC insertion machine. Straight terminals are available for manual insertion. Low contact resistance, and self-clean on contact area. Gold plated electrical contact and terminal plating by gold gives excellent results when soldering. All materials are UL94V-0 grade fire retardant plastics. ITEM Description Materials 1 2 3 4 5 Actuator Cover Base Contact Terminal UL94V-0 Nylon UL94V-0 Nylon UL94V-0 Nylon Treatment Molded white Molded black Molded black Gold plated at contact area and gold plating at terminal CIRCUIT DIAGRAM Beryllium Copper Gold plated at contact area Brass DB LECTRO Inc. 3755 Place Java, Suite 140, Brossard, Québec, J4Y 0E4, Canada - T: 1-450-444-1424 / F: 1-450-444-4714 / www.dblectro.com MODEL PROD NO. RI/RIR-01 RI/RIR-02 RI/RIR-03 RI/RIR-04 RI/RIR-05 RI/RIR-06 RI/RIR-07 RI/RIR-08 RI/RIR-09 RI/RIR-10 RI/RIR-12 HOW TO ORDER NO. OF POS 01 02 03 04 05 06 07 08 09 10 12 DIM A 3.48 6.02 8.56 11.1 13.64 16.18 18.72 21.26 23.8 26.34 31.42 0.137 0.237 0.337 0.437 0.537 0.637 0.737 0.837 0.937 1.037 1.237 SPECIFICATION ELECTRICAL Electrical life: 2000 operation cycles per switch 24VDC, 25mA. Non-Switching Rating: 100mA, 50 VDC Switching Rating: 25mA, 24VCD. Contact resistance: (a) 50mΩ max. at initial (b) 100mΩ max. after life test. Insulation resistance: 100MΩ min. (at 500VDC) Dielectric Strength: 500VAC/1 minute. Capacitance: 5pF max. Circuit: Single pole single throw MECHANICAL Mechanical life: 2000 operations per cycle switch Operation Force: 600gf max. Stroke: 0.9mm Operation Temp: -25° C to +70° C Storage Temp: -40° C to +85° C Vibration Test: MIL-STD-202F METHOD 201A Frequency: 10-55-10Hz/1 min Directions: X, Y, Z, three mutually perpendicular directions. Time: 2 hours each direction. High reliability. Shock Test: MIL-STD-202F METHOD 213B. CONDITION A GRAVITY: 50G (peak value), 11 m/sec. Direction and times: 6 sides and three times in each direction. High reliability. SOLDERING AND CLEANING PROCESSES For best results, please follow these recommendations: Keep all switch contacts in their "OFF" position for all operations. WAVE SOLDERING: Recommended solder temperature at 500 F (260° C) max. 5 seconds. HAND SOLDERING: Use a soldering iron of 30 watts, controlled at 608 F(320° C) approximately 2 seconds while applying solder. CLEANING PROCESS: Flux clean using force rinse, high agitation or triple bath cleaning method. Freon TF or TE give excellent results. When vapor methods are used, do not subject the switch to solvents at temperatures above 125 F (51° C). TERMINAL TYPE Example: RI-08G-S is a Machine Insertable Type Dip Switch, Raised Actuator 8 position, splay terminal. PACKING All DIP switches are shipped in standard IC tubes with all poles in "OFF" position. DB LECTRO Inc. 3755 Place Java, Suite 140, Brossard, Québec, J4Y 0E4, Canada - T: 1-450-444-1424 / F: 1-450-444-4714 / www.dblectro.com

下载 PDF

RI-12

1. 物料型号： - 型号包括RI/RIR-01至RI/RIR-12，表示不同的引脚数量。

2. 器件简介： - 该文档描述了DIP开关，包括凸起式执行器（RI系列）和凹陷式执行器（RIR系列），适用于不同的应用场景。开关设计允许通过IC插入机自动插入，并且有直脚和splay脚两种类型，分别适用于手动和自动插入。

3. 引脚分配： - 提供了不同型号的DIP开关的引脚数量和尺寸，例如RI/RIR-01为3.48mm，RI/RIR-02为6.02mm等。

4. 参数特性： - 电气特性：每个开关的电气寿命为2000次操作周期，24VDC，25mA。非开关额定值：100mA，50VDC。开关额定值：25mA，24VDC。接触电阻：初始时最大50mΩ，寿命测试后最大100mΩ。绝缘电阻：最小100MΩ（500VDC）。耐压：500VAC/1分钟。电容：最大5pF，单极单掷电路。 - 机械特性：机械寿命：每个周期2000次操作。操作力：最大600gf。行程：0.9mm。操作温度：-25°C至+70°C。存储温度：-40°C至+85°C。

5. 功能详解： - 描述了DIP开关的机械和电气特性，包括操作力、行程、操作温度范围、存储温度范围以及振动和冲击测试标准。

6. 应用信息： - DIP开关通常用于电子设备中，允许用户通过手动或自动方式改变电路配置。

7. 封装信息： - 所有DIP开关都使用标准IC管包装，所有极位默认为“OFF”位置。
