RM-02

RM SERIES RM & RMR CONSTRUCTION P.C.B. LAYOUT RM series 1. 2. 3. 4. 5. RMR series RM series (raised actuator) and RMR series (recessed actuator) available for different purposes. Low contact resistance, and self-clean on contact area. Gold plated electrical contact and terminal plating by gold give excellent results when soldering. Double contacts offer high reliability. All materials are UL94V-0 grade fire retardant plastics. ITEM Description Materials 1 2 3 4 5 Actuator Cover Base Contact Terminal UL94V-0 Nylon UL94V-0 Nylon UL94V-0 Nylon Brass Treatment Molded white Molded black Molded black Gold plated at contact area CIRCUIT DIAGRAM Beryllium Copper Gold plated at contact area DB LECTRO Inc. 3755 Place Java, Suite 140, Brossard, Québec, J4Y 0E4, Canada - T: 1-450-444-1424 / F: 1-450-444-4714 / www.dblectro.com MODEL PROD NO. RM/RMR-01 RM/RMR-02 RM/RMR-03 RM/RMR-04 RM/RMR-05 RM/RMR-06 RM/RMR-07 RM/RMR-08 RM/RMR-09 RM/RMR-10 RM/RMR-12 NO. OF POS 01 02 03 04 05 06 07 08 09 10 12 DIM A 3.48 6.02 8.56 11.1 13.64 16.18 18.72 21.26 23.8 26.34 31.42 0.137 0.237 0.337 0.437 0.537 0.637 0.737 0.837 0.937 1.037 1.237 TERMINAL TYPE HOW TO ORDER Tape & reel packing (Per EIA standards) For packing details, please refer to pages 13 SPECIFICATION ELECTRICAL Electrical life: 2000 operation cycles per switch 24VDC, 25mA. Non-Switching Rating: 100mA, 50 VDC Switching Rating: 25mA, 24VCD. Contact resistance: (a) 50mΩ max. at initial (b) 100mΩ max. after life test. Insulation resistance: 100MΩ min. (at 500VDC) Dielectric Strength: 500VAC/1 minute. Capacitance: 5pF max. Circuit: Single pole single throw MECHANICAL Mechanical life: 2000 operations per cycle switch Operation Force: 600gf max. Stroke: 0.9mm Operation Temp: -25° C to +70° C Storage Temp: -40° C to +85° C Vibration Test: MIL-STD-202F METHOD 201A Frequency: 10-55-10Hz/1 min Directions: X, Y, Z, three mutually perpendicular directions. Time: 2 hours each direction. High reliability. Shock Test: MIL-STD-202F METHOD 213B. CONDITION A GRAVITY: 50G (peak value), 11 m/sec. Direction and times: 6 sides and three times in each direction. High reliability. Example: RMR-08G-T is a surface mounting Type Dip Switch, Recessed Actuator 8 position, with, top tape sealed. DB LECTRO Inc. 3755 Place Java, Suite 140, Brossard, Québec, J4Y 0E4, Canada - T: 1-450-444-1424 / F: 1-450-444-4714 / www.dblectro.com SOLDERING AND CLEANING PROCESSES PACKING All DIP switches are shipped in standard IC tubes or Tape & Reel Package with all poles in the "OFF" position. CARRIER TAPE PACKING For best results, please follow these recommendations: Keep all switch contacts in their "OFF" position for all operations. Soldering: vapor phase & IR-reflow soldering can be applied. CLEANING PROCESS: Flux clean using force rinse, high agitation or triple bath cleaning method. Freon TF or TE give excellent results. When vapor methods are used, do not subject the switch to solvents at temperatures above 125 F (51° C). Reflow Temperature Profile. (reference) PART NO. RMR-02G-T-R RMR-03G-T-R RMR-04G-T-R RMR-05G-T-R RMR-06G-T-R RMR-07G-T-R RMR-08G-T-R RMR-09G-T-R RMR-10G-T-R RMR-12G-T-R NO. OF POS 02 03 04 05 06 07 08 09 10 12 A 6.50 9.00 B 5.5 7.5 C 16 16 Q'TY/REEL 800 pcs 800 pcs 800 pcs 800 pcs 800 pcs 800 pcs 800 pcs 800 pcs 800 pcs 800 pcs CARRIER TAPE PACKING 11.50 11.5 24 14.10 11.5 24 16.60 14.2 32 19.10 14.2 32 21.70 14.2 32 24.20 20.2 44 26.70 20.2 44 31.90 20.2 44 DB LECTRO Inc. 3755 Place Java, Suite 140, Brossard, Québec, J4Y 0E4, Canada - T: 1-450-444-1424 / F: 1-450-444-4714 / www.dblectro.com
