RPL-12

P.C.B. LAYOUT RPL & RP CONSTRUCTION RPL series 1. 2. 3. 4. 5. RP series Terminal plating by gold gives excellent results when soldering. RPL series (raised actuator) and RP series (recessed actuator) Low contact resistance, and self-clean on contact area. Double contacts offer high reliability. All materials are UL94V-0 grade fire retardant plastics. ITEM 1 2 3 4 5 Description Actuator Cover Base Terminal Potting Materials UL94V-0 PBT UL94V-0 PBT UL94V-0 PBT Phosphor bronze Epoxy Treatment White Blue, Red, Black Black Gold Plating Black DB LECTRO Inc. 3755 Place Java, Suite 140, Brossard, Québec, J4Y 0E4, Canada - T: 1-450-444-1424 / F: 1-450-444-4714 / www.dblectro.com MODEL PROD NO. RPL/RP-02 RPL/RP-03 RPL/RP-04 RPL/RP-05 RPL/RP-06 RPL/RP-08 RPL/RP-10 RPL/RP-12 HOW TO ORDER NO. OF POS 02 03 04 05 06 08 10 12 DIM A 6.26 9.06 11.34 13.88 16.42 21.5 26.58 31.60 0.246 0.357 0.446 0.546 0.646 0.846 1.046 1.244 CIRCUIT DIAGRAM TERMINAL TYPE SPECIFICATION ELECTRICAL Electrical life: 2000 operation cycles per switch 24VDC, 25mA. Non-Switching Rating: 100mA, 50 VDC Switching Rating: 25mA, 24VCD. Contact resistance: (a) 50mΩ max. at initial (b) 100mΩ max. after life test. Insulation resistance: 100MΩ min. (at 500VDC) Dielectric Strength: 500VAC/1 minute. Capacitance: 5pF max. Circuit: Single pole single throw. MECHANICAL Mechanical life: 2000 operations per cycle switch Operation Force: 400gf max. Stroke: 2.0mm Operation Temp: -25° C to +70° C Storage Temp: -40° C to +85° C Vibration Test: MIL-STD-202F METHOD 201A Frequency: 10-55-10Hz/1 min Directions: X, Y, Z, three mutually perpendicular directions. Time: 2 hours each direction. High reliability. Shock Test: MIL-STD-202F METHOD 213B. CONDITION A GRAVITY: 50G (peak value), 11 m/sec. Direction and times: 6 sides and three times in each direction. High reliability. SOLDERING AND CLEANING PROCESSES For best results, please follow these recommendations: Keep all switch contacts in their "OFF" position for all operations. Example: RPL-08-B-T is a Piano Type Dip Switch, Long key, 8 position with top tape sealed. PACKING All Dip Switches are shipped in standard IC tubes with all poles in "OFF" position. DB LECTRO Inc. 3755 Place Java, Suite 140, Brossard, Québec, J4Y 0E4, Canada - T: 1-450-444-1424 / F: 1-450-444-4714 / www.dblectro.com WAVE SOLDERING: Recommended solder temperature at 500 F (260° C) max. 5 seconds. HAND SOLDERING: Use a soldering iron of 30 watts, controlled at 608 F(320° C) approximately 2 seconds while applying solder. CLEANING PROCESS: Flux clean using force rinse, high agitation or triple bath cleaning method. Freon TF or TE give excellent results. When vapor methods are used, do not subject the switch to solvents at temperatures above 125 F (51° C). DB LECTRO Inc. 3755 Place Java, Suite 140, Brossard, Québec, J4Y 0E4, Canada - T: 1-450-444-1424 / F: 1-450-444-4714 / www.dblectro.com
