521-9450_1

521 SERIES 5mm Discrete LED 3 Leaded, Non-Tinted, Diffused BI-COLOR PART NUMBER 521-9450 521-9461 LED COLOR RED/GREEN YELLOW/GREEN SPECIFICATIONS 521-9450 .362 [9,19] .332 [8,44] .060 ±.010 [ 1,53 ±0,25 ] 1.040 [ 26,42 REF ] .020 SQ. [ 0,51 ] NOM. TYP. GREEN ANODE COMMON CATHODE .200 [5,08] .180 [4,58] .200 NOM. [ 5,08 ] .150 MAX. [ 3,82 ] SPECIFICATIONS AMBER ANODE .990 [ 25,15 1.050 [ 26,67 REF ] MIN. ] .100 NOM. [ 2,54 ] TYP. 2 521-9461 .362 [9,19] .332 [8,44] .060 ±.010 [ 1,53 ±0,25 ] 1.040 [ 26,42 REF ] .020 SQ. [ 0,51 ] NOM. TYP. GREEN ANODE COMMON CATHODE .200 [5,08] .180 [4,58] .200 NOM. [ 5,08 ] .100 NOM. [ 2,54 ] TYP. 2 .150 MAX. [ 3,82 ] .990 [ 25,15 1.050 [ 26,67 REF ] MIN. ] AMBER ANODE ABSOLUTE MAXIMUM RATINGS (TA= 25OC) Power Dissipation (mW): Average Forward Current (mA): Derating (mA/oC) From 50 C o 135/135 25/25 .5/.5 90/90 Operating Temperature (oC): Storage Temperature ( C): o -20/+85 -55/+85 260oC, 5 seconds, 1.6 mm from case Soldering Temperature: Peak Current (mA): OPERATING CHARACTERISTICS (TA= 25OC) Part Number 521-9450 521-9461 *IF = 10mA Color Red/Green Yellow/Green Peak Wavelength (nm) 635/565 583/565 Luminous Intensity (mcd) Min. 2.1/4.2 Min. 2.1/4.2 Typ. 5/8 Typ. 5/8 Forward Voltage (V)* Typ. 2.1/2.3 Typ. 2.1/2.1 Max. 2.5/2.7 Max. 2.5/2.5 Viewing Angle 20 1/2 65o 65o Dialight Corporation 1501 Route 34 South • Farmingdale, NJ 07727 USA Tel: (1) 732-919-3119 • Fax: (1) 732-751-5778 • www.dialight.com a Roxboro Group Company MDEA521X001_A
