550-5507

FEATURES / BENEFITS Multiple CBIs form horizontal LED arrays on 6.35mm (0.250”) center-lines. High contrast, UL 94 V-0 rated, black housing Oxygen index: 32% Polymer content: PBT, 0.206 g Housing stand-offs facilitate PCB cleaning Solderability per MIL-STD-202F, method 208F LEDs are safe for direct viewing per IEC 825-1, EN-60825-1 550 SERIES 5mm LED CBI® Circuit Board Indicator Sloped Back Housing with Standoffs Compatible with: 550-xx07 Dual Block and 550-xx07-004 Quad Block PART NUMBER GENERAL PURPOSE 550-0207 550-0307 550-0407 INTEGRAL RESISTOR 550-0507 550-0707 550-0807 Dimension A: 3.43 [.135] for -0207 to -0407, 4.83 [.190] for all others Dimension B: .635 [.025] for -0507 to -0707, .508 [.020] for all others Hole Diameter: 1.22 [.48] for .635 [.025] leads, 1.02 [.040] for all others COLOR Green Yellow Red Red, 5V Green, 5V Yellow, 5V Red Yellow Green Green Yellow Red Orange Red/Green Yellow/Green Red Green Yellow Red Green Yellow LOW CURRENT 550-1107 550-1207 550-1307 HIGH EFFICIENCY 550-2207 550-2307 550-2407 550-2507 Standard Polarity shown in drawing: Cathode right PART NUMBER ORDERING CODE 550 Series xx07 LED Type 010 Reverse Polarity Option 1) Cathode Left BI-COLOR 550-3007 550-3107 SUPER BRIGHT, DIFFUSED 550-5107 550-5207 550-5307 550-5507 550-5607 550-5707 Contact factory for information on custom color combinations. TOLERANCE NOTE: As noted, otherwise: • LED Protrusion: +0.41mm [+0.016] • CBI Housing: +0.20mm [+ 0.008] To order any of the 550-xx07 part numbers with Reverse Polarity (Cathode Left), please add -010 to the part numbers shown above. SUPER BRIGHT, WATER CLEAR (Non-tinted, Non-diffused) Dialight Corporation 1501 Route 34 South • Farmingdale, NJ 07727 USA Tel: (1) 732-919-3119 • Fax: (1) 732-751-5778 • www.dialight.com a Roxboro Group Company MDEA550X001_A
