570-0100-222

2mm LED CBI® Circuit Board Indicator (DIN 41494 Compatible), Tri-Level PART NO. 5.08 [.200] 1.80 [.071] 3.30 [.130] 10.16 [.400] 3.30 [.130] 1.78 [.070] 3.20 [.126] ANODE 0.46 [.018] 6.84 [.269] .4 [.017] REF 2.54 [.100] Ø 0.965 ±.05 [.038±.002] 2.54 [.100] 2.54 [.100] 2.54 [.100] 2.54 [.100] TOP LED .41 [.016] SQ. 1.52 [.060] 12.85 [.506] 570-0100-xxx COLOR* Red–Red–Red Red–Yellow–Green Green–Green–Green Yellow–Yellow–Yellow 570-0100-111 570-0100-132 570-0100-222 570-0100-333 * Top-Middle-Bottom LED 3 RECOMMENDED P.C. BOARD LAYOUT Dimensions in mm [inches] Features • Designed to accommodate DIN 41494 • Multiple CBIs form horizontal LED arrays on 5.08mm • • • • (0.200”) center-lines High Contrast, UL 94 V-0 rated, black housing Oxygen index: 29% Polymer content: PBT, 0.595 g Housing stand-offs facilitate PCB cleaning Custom Combinations • Contact factory for information on custom color combinations. EXAMPLE OF PART NUMBER ORDERING CODE Series Top LED Color • Solderability per MIL-STD-202F, method 208F • LEDs are safe for direct viewing per IEC 825-1, EN- 60825-1 570-0100-xxx Middle LED Color LED colors: 0) Blank 1) Red 2) Green 3) Yellow Bottom LED Color Tolerance note: As noted, otherwise: • LED Protrusion: ±0.04 mm [±0.016] • CBI Housing: ±0.02mm[±0.008] See LED data sheet for additional information See Page 3-17 and 3-18 for Reference Only LED Drive Circuit Examples See Page 3-19 for Pin Out Typical Operating Characteristics (TA = 25°C) GENERAL PURPOSE Peak Wavelength nm 635 565 585 IV* mcd 12.6 8.7 12.6 V F ** Volts 2 2.1 2.1 Part Number 570-0100-xxx * I F = 10 mA Color Red Green Yellow Viewing Angle 2 Θ1/2 38° 38° 38° LED Data sheet 521-9630 521-9632 521-9631 Page # 3-13 3-13 3-13 **I F = 20 mA Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com 3-11 2mm Discrete LED Diffused 521-9630, -9631, -9632 CATHODE I.D. 2.40 [.095] 2.90 [.114] 25.40 [1.00] MIN CATHODE 3.30 [.13] 1.80 [.071] .45 [.018] TYP .40 [.016] TYP 1.00 [.04] MIN 2.54 [.10] NOM PART NO. 521-9630 521-9631 521-9632 COLOR Red Yellow Green R 1.65 [.065] 1.52 [.060] 3.30 [.130] 1.50 [.059] MAX Dimensions in mm [inches] 3 Red Yellow Green ABSOLUTE MAXIMUM RATINGS (TA=25°C) Power Dissipation (mW) Forward Current (mA) Derating (mA/°C) From 25°C Peak Current (mA) Pulse width = 10µs -9630 100 30 .4 120 -55/+100 -55/+100 -9631 60 20 .25 80 -55/+100 -55/+100 -9632 100 30 .4 120 -55/+100 -55/+100 Operating Temperature (°C) Storage Temperature (°C) Soldering Temperature 260°C, 5 seconds, 1.6 mm from case Red Yellow Green OPERATING CHARACTERISTICS (TA=25°C) Luminous Intensity (mcd) IF=10mA Peak Wavelength (nm) λ Peak Viewing Angle (2 Θ1/2) Forward Voltage (V) IF=20mA Reverse Voltage (V), IR=100µA Min. Typical Typical Typical Typical Max. Min. -9630 3.7 12.6 635 38° 2 2.8 5 -9631 3.7 12.6 585 38° 2.1 2.8 5 -9632 2.5 8.7 565 38° 2.1 2.8 5 Θ 1¼2is the off axis angle at which the luminous intensity is half the axial luminous intensity Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com 3-13
