585-3425

FEATURES / BENEFITS Low current draw - uses up to 90% less energy than incandescent Long Life - up to 100K hours True non-polarized configurations available No heat generated Mounts directly into industry standard socket Available in 6, 14, and 28 VDC Dialight's line of based LED lamps is designed to directly replace many popular subminiature and miniature incandescent lamps. The benefits of LED technology over incandescent are significant: They offer long life, are shock resistant, withstand vibration and provide energy conservation. 585 Series Multi-Chip BASED LED T1 3/4 Bi-Pin SPECIFICATIONS Operating Voltages: 6, 14, and 28 VDC Polarized and non-polarized available Operating temperature: -20oC to +60oC Storage temperature: -30oC to +100oC Replaces incandescent lamp numbers*: 2314, 2323, 2324, 2325, 2335, 2337, 2342, 7327, 7328, 7330, 7349, 7377, 7380, 7381, 7382, 7387, 7876, and 7945. * Measurements are typical Dimensions are inches [mm] See Dialight’s Incandescent lamp/based LED cross reference for a complete listing (polarized version) CONSIDERATIONS Since lens caps act as filters for the light emitted from the based LED, it is important to match the emitting color of the LED. If not matched properly, the overall light output may be substantially reduced. Dialight recommends using transparent lenses, which will optimize the light output. If you are unfamiliar with the polarity of the circuit, Dialight recommends using a non-polarized version. Although these lamps can be operated at a lower voltage, which will increase the life, the intensity will be reduced. Operation of the based LED at a higher voltage should not exceed 10% above the recommended voltage. Dialight does not recommend that based LED lamps be used in neon sockets. Dialight reserves the right to make changes at any time in order to supply the best product possible. Dialight Corporation 1501 Route 34 South • Farmingdale, NJ 07727 USA Tel: (1) 732-919-3119 • Fax: (1) 732-751-5778 • www.dialight.com a Roxboro Group Company MDEL585BP001_B 585 Series Multi-Chip BASED LED T1 3/4 Bi-Pin POLARIZED Part Number 585-3211 585-3311 585-3411 585-3213 585-3313 585-3413 585-3215 585-3315 585-3415 Color Red Green Yellow Red Green Yellow Red Green Yellow Peak Wavelength (nm) 660 565 585 660 565 585 660 565 585 Voltage (VDC) 6 6 6 14 14 14 28 28 28 Current TYP.-(mA) 50 46 44 30 28 30 16 15 15 Intensity TYP.-(mcd) 67 77 22 60 70 23 64 75 23 NON-POLARIZED Peak Wavelength (nm) 660 565 585 660 565 585 660 565 585 Part Number 585-3221 585-3321 585-3421 585-3223 585-3323 585-3423 585-3225 585-3325 585-3425 Color Red Green Yellow Red Green Yellow Red Green Yellow Voltage (VDC) 6 6 6 14 14 14 28 28 28 Current TYP.-(mA) 75 67 73 26 23 24 14 13 13 Intensity TYP.-(mcd) 50 56 18 50 56 18 56 65 20 Based LE Ds SELECTION With the technological advancements in Light Emitting Diodes (LEDs) brightness can now rival the incandescent lamp when used in similar packages. These advancements have created a new type of product called the based LED - an LED with the functionality of an incandescent bulb. The following styles are currently available in red, green, yellow, blue and white: T1 3/4 Midget Flange T1 3/4 Bi-Pin T1 3/4 Wedge (T5) T3 1/4 Miniature Bayonet (BA9s) T3 1/4 Miniature Screw (E10) T3 1/4 Wedge (T10) T2 Telephone Slide 15mm SC Bayonet (BA15s) Dialight’s line of based LEDs continues to grow. Please visit our website for more information. www.dialight.com Dialight reserves the right to make changes at any time in order to supply the best product possible. Dialight Corporation 1501 Route 34 South • Farmingdale, NJ 07727 USA Tel: (1) 732-919-3119 • Fax: (1) 732-751-5778 • www.dialight.com a Roxboro Group Company MDEL585BP001_B
