1N5711

1N5711 SCHOTTKY BARRIER SWITCHING DIODE Features · · · · Ultra-Fast Switching Speed High Reverse Breakdown Voltage Low Forward Voltage Drop Guard Ring Junction Protection A B A Mechanical Data · · · · · Case: DO-35, Glass Leads: Solderable per MIL-STD-202, Method 208 Marking: Type Number Polarity: Cathode Band Weight: 0.13 grams (approx.) Dim A B C D D DO-35 Min 25.40 ¾ ¾ ¾ Max ¾ 4.00 0.60 2.00 C All Dimensions in mm Maximum Ratings @ TA = 25°C unless otherwise specified Symbol VRRM VRWM VR VR(RMS) IFM Pd RqJA Tj TSTG @ TA = 25°C unless otherwise specified Symbol V(BR)R IR VF Cj trr Min 70 ¾ ¾ ¾ ¾ Max ¾ 200 0.41 1.00 2.0 1.0 Unit V nA V pF ns Test Condition IR = 10mA VR = 50V IF = 1.0mA IF = 15mA VR = 0V, f = 1.0MHz IF = IR = 5.0mA, Irr = 0.1 x IR, RL = 100W 1N5711 70 49 15 400 300 -55 to +125 -55 to +150 Unit V V mA mW °C/W °C °C Characteristic Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Forward Continuous Current Power Dissipation (Note 1) Thermal Resistance, Junction to Ambient Air (Note 1) Operating Temperature Range Storage Temperature Range Electrical Characteristics Characteristic Reverse Breakdown Voltage (Note 2) Reverse Leakage Current (Note 2) Forward Voltage Drop (Note 2) Junction Capacitance Reverse Recovery Time Notes: 1. Valid provided that leads are kept at ambient temperature. 2. Short duration test pulse used to minimize self-heating effect. DS11011 Rev. F-2 1 of 2 1N5711 10 100 IF, FORWARD CURRENT (mA) IF, FORWARD CURRENT (mA) 80 1.0 60 40 0.1 20 0.01 0 0.5 VF, FORWARD VOLTAGE (V) Fig. 1 Typical Forward Characteristics 100 Tj = 150°C 1.0 0 0 0.5 VF, FORWARD VOLTAGE (V) Fig. 2 Typical Forward Characteristics 2 Tj = 25°C 1 IR, REVERSE CURRENT (mA) Tj = 100°C Cj, CAPACITANCE (pF) 10 Tj = 125°C 1 Tj = 75°C 1 0.1 Tj = 50°C Tj = 25°C 0.01 0 0 10 20 30 40 50 0 10 20 30 40 50 VR, REVERSE VOLTAGE (V) Fig. 3 Typical Reverse Characteristics VR, REVERSE VOLTAGE (V) Fig. 4 Typ. Junction Capacitance vs Reverse Voltage DS11011 Rev. F-2 2 of 2 1N5711
