1N6263

1N6263 SCHOTTKY BARRIER SWITCHING DIODE Features · · · · Low Forward Voltage Drop Guard Ring Construction for Transient Protection Fast Switching Time Low Reverse Capacitance A B A Mechanical Data · · · · · Case: DO-35, Glass Leads: Solderable per MIL-STD-202, Method 208 Marking: Type Number Polarity: Cathode Band Weight: 0.13 grams (approx.) Dim A B C D D DO-35 Min 25.40 ¾ ¾ ¾ Max ¾ 4.00 0.60 2.00 C All Dimensions in mm Maximum Ratings @ TA = 25°C unless otherwise specified Symbol VRRM VRWM VR VR(RMS) IFM IFSM Pd RqJA Tj TSTG @ TA = 25°C unless otherwise specified Symbol V(BR)R VF IR Cj trr Min 60 ¾ ¾ ¾ ¾ Typ ¾ ¾ ¾ ¾ ¾ Max ¾ 0.41 1.0 200 2.2 1.0 Unit V V nA pF ns Test Condition IR = 10mA IF = 1.0mA IF = 15mA VR = 50V VR = 0V, f = 1.0MHz IF = IR = 5.0mA, Irr = 0.1 x IR, RL = 100W 1N6263 60 42 15 50 2.0 400 300 -55 to +125 -55 to +150 Unit V V mA mA A mW °C/W °C °C Characteristic Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Forward Continuous Current Non-Repetitive Peak Forward Surge Current @ t £ 1.0s @ t = 10ms Power Dissipation (Note 1) Thermal Resistance, Junction to Ambient Air (Note 1) Operating Temperature Range Storage Temperature Range Electrical Characteristics Characteristic Reverse Breakdown Voltage (Note 2) Forward Voltage Drop (Note 2) Reverse Leakage Current (Note 2) Junction Capacitance Reverse Recovery Time Notes: 1. Valid provided that leads are kept at ambient temperature. 2. Short duration test pulses used to minimize self-heating effect. DS11010 Rev. F-2 1 of 2 1N6263 10 100 IF, FORWARD CURRENT (mA) IF, FORWARD CURRENT (mA) 80 1.0 60 40 0.1 20 0.01 0 0.5 VF, FORWARD VOLTAGE (V) Fig. 1 Typical Forward Characteristics 100 Tj = 150°C 0 1.0 0 0.5 VF, FORWARD VOLTAGE (V) Fig. 2 Typical Forward Characteristics 1 2 Tj = 25°C IR, REVERSE CURRENT (mA) Tj = 100°C Cj, CAPACITANCE (pF) 40 50 10 Tj = 125°C 1 Tj = 75°C 1 0.1 Tj = 50°C Tj = 25°C 0.01 0 0 10 20 30 0 10 20 30 40 50 VR, REVERSE VOLTAGE (V) Fig. 3 Typical Reverse Characteristics VR, REVERSE VOLTAGE (V) Fig. 4 Typ. Junction Capacitance vs Reverse Voltage DS11010 Rev. F-2 2 of 2 1N6263
