AP1603
STEP-UP DC/DC CONVERTER
Features
• • • • • • • A Guaranteed Start-Up from less than 0.9 V High Efficiency Low Quiescent Current Less Number of External Components needed Low Ripple and Low Noise Space Saving Lead-Free Packages: SOT26 Lead Free Finish/RoHS Compliant for Lead Free products (Note 1)
General Description
The AP1603 is a high efficiency step-up DC/DC converter for applications using as few as a single NiMH or Li-Ion battery cells. Only four external components are required to deliver a fixed output voltage of 3.3V. The AP1603 starts up from less than 0.9V input with 1mA load. Pulse Frequency Modulation scheme brings optimized performance for applications with light output loading and low input voltages. The output ripple and noise are lower compared with the circuits operating in PSM mode. The PFM control circuit operating in 150KHz (max.) switching rate results in smaller passive components. The space saving SOT26 packages make the AP1603 an ideal choice of DC/DC converter for space conscious applications, like pagers, electronic cameras, and wireless microphones.
Applications
• • • • • • Pagers Cameras Wireless Microphones Pocket Organizers Battery Backup Suppliers Portable Instruments
Ordering Information
A P1603 X X X
Package W : SOT26
Lead-Free L : Lead-Free (Note 2)
Packing - 7 : Taping
Note:
1. RoHS revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see EU Directive Annex Notes 5 and 7.
Device
Lead-free
Package Code
W
Packaging (Note 2)
SOT26
7” Tape and Reel Quantity Part Number Suffix
3000/Tape & Reel -7
AP1603W
Note:
2. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.
AP1603 Rev. 1
1 of 8 www.diodes.com
NOVEMBER 2006
© Diodes Incorporated
AP1603
STEP-UP DC/DC CONVERTER
Pin Assignments
Pin Descriptions
FB 1 GND 2 REF 3 SOT26 AP1603
6 SHDN 5 OUT 7 LX 4
Name FB Feedback
Description
GND Ground 1.2V Reference Voltage. Bypass with a REF 0.1µF capacitor. N-Channel and P-Channel Power MOSFET LX Drain Power Output. OUT provides bootstrap OUT power to the IC. Shutdown Input. Drive high (>80% of VOUT) for operating mode. Drive low (
