AP2151D

AP2141D/AP2151D 0.5A SINGLE CHANNEL CURRENT-LIMITED POWER SWITCH WITH OUTPUT DISCHARGE Description The AP2141D and AP2151D are integrated high-side power switches optimized for Universal Serial Bus (USB) and other hot-swap applications. The family of devices complies with USB 2.0 and available with both polarities of Enable input. They offer current and thermal limiting and short circuit protection as well as controlled rise time and under-voltage lockout functionality. A 7ms deglitch capability on the opendrain Flag output prevents false over-current reporting and does not require any external components. All devices are available in SOT25, SO-8, MSOP-8-EP, and DFN2018-6 packages. Pin Assignments ( Top View ) GND IN IN 1 2 3 8 7 6 5 NC OUT OUT FLG N EW PRODUCT EN 4 SO-8 Features • • • • • • • • • • • • • • Single USB port power switches with output discharge Over-current and thermal protection 0.8A accurate current limiting Fast transient response Reverse Current Blocking 90mΩ on-resistance Input voltage range: 2.7V – 5.5V 0.6ms typical rise time Very low shutdown current: 1µA (max) Fault report (FLG) with blanking time (7ms typ) ESD protection: 4KV HBM, 300V MM Active high (AP2151D) or active low (AP2141D) enable Ambient temperature range -40ºC to 85°C SOT25, SO-8, MSOP-8-EP (Exposed Pad), and DFN2018-6: Available in “Green” Molding Compound (No Br, Sb) Lead Free Finish / RoHS Compliant (Note 1) UL Recognized, File Number E322375 (pending) IEC60950-1 CB Scheme Certified ( Top View ) GND IN IN EN 1 2 3 4 8 7 6 5 NC OUT OUT FLG MSOP-8-EP ( Top View ) OUT GND FLG 1 2 3 4 5 IN • • • EN SOT25 Applications ( Top View ) • • • Consumer electronics – LCD TV & Monitor, Game Machines Communications – Set-Top-Box, GPS, Smartphone Computing – Laptop, Desktop, Servers, Printers, Docking Station, HUB GND IN EN 1 6 OUT OUT FLG 2 5 3 4 DFN2018-6 Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at http://www.diodes.com/products/lead_free.html. AP2141D/2151D Document number: DS32242 Rev. 1 - 2 1 of 18 www.diodes.com June 2010 © Diodes Incorporated AP2141D/AP2151D 0.5A SINGLE CHANNEL CURRENT-LIMITED POWER SWITCH WITH OUTPUT DISCHARGE Typical Application Circuit AP2151D Enable Active High Power Supply 2.7V to 5.5V 10k 10uF 0.1uF IN OUT 0.1uF Load 120uF FLG N EW PRODUCT ON OFF EN GND Available Options Part Number AP2141D AP2151D Channel 1 1 Enable pin (EN) Active Low Active High Current limit (typical) 0.8A 0.8A Recommended maximum continuous load current 0.5A 0.5A Pin Descriptions Pin Number Pin Name GND IN EN FLG OUT NC SO-8 MSOP-8-EP 1 2, 3 4 5 6, 7 8 SOT25 2 5 4 3 1 N/A DFN2018-6 1 2 3 4 5, 6 N/A Ground Voltage input pin (all IN pins must be tied together externally) Enable input, active low (AP2141D) or active high (AP2151D) Over-current and over-temperature fault report; open-drain flag is active low when triggered Voltage output pin (all OUT pins must be tied together externally) No internal connection; recommend tie to OUT pins Descriptions AP2141D/2151D Document number: DS32242 Rev. 1 - 2 2 of 18 www.diodes.com June 2010 © Diodes Incorporated AP2141D/AP2151D 0.5A SINGLE CHANNEL CURRENT-LIMITED POWER SWITCH WITH OUTPUT DISCHARGE Functional Block Diagram IN Current Sense UVLO Driver Current Limit Discharge Control OUT N EW PRODUCT EN FLG Thermal Sense Deglitch GND Absolute Maximum Ratings Symbol ESD HBM ESD MM VIN VOUT VEN , VFLG Iload TJmax TST Notes: Parameter Human Body Model ESD Protection Machine Model ESD Protection Input Voltage Output Voltage Enable Voltage Maximum Continuous Load Current Maximum Junction Temperature Storage Temperature Range (Note 2) Ratings 4 300 6.5 VIN + 0.3 6.5 Internal Limited 150 -65 to 150 Unit KV V V V V A °C °C 2. UL Recognized Rating from -30°C to 70°C (Diodes qualified TST from -65°C to 150°C) Recommended Operating Conditions Symbol VIN IOUT TA Parameter Input voltage Output Current Operating Ambient Temperature Min 2.7 0 -40 Max 5.5 500 85 Unit V mA °C AP2141D/2151D Document number: DS32242 Rev. 1 - 2 3 of 18 www.diodes.com June 2010 © Diodes Incorporated AP2141D/AP2151D 0.5A SINGLE CHANNEL CURRENT-LIMITED POWER SWITCH WITH OUTPUT DISCHARGE Electrical Characteristics (TA = 25oC, VIN = +5.0V, unless otherwise stated) Symbol VUVLO ISHDN IQ ILEAK IREV Parameter Input UVLO Input Shutdown Current Input Quiescent Current Input Leakage Current Reverse Leakage Current Disabled, IOUT= 0 Enabled, IOUT= 0 Disabled, OUT grounded Disabled, VIN= 0V, VOUT= 5V, IREV at VIN VIN = 5V, IOUT= 0.5A VIN = 3.3V, IOUT= 0.5A ISHORT ILIMIT ITrig VIL VIH ISINK TD(ON) TR TD(OFF) TF RFLG TBlank RDIS TDIS TSHDN THYS Short-Circuit Current Limit Over-Load Current Limit Current limiting trigger threshold EN Input Logic Low Voltage EN Input Logic High Voltage EN Input leakage Output turn-on delay time Output turn-on rise time Output turn-off delay time Output turn-off fall time FLG output FET on-resistance FLG blanking time Discharge resistance (Note 3) Discharge Time Thermal Shutdown Threshold Thermal Shutdown Hysteresis SOT25 (Note 4) θJA Thermal Resistance Junctionto-Ambient SO-8 (Note 4) MSOP-8-EP (Note 5) DFN2018-6 (Note 5) Notes: Test Conditions Min 1.6 Typ. 1.9 0.5 45 0.1 0.1 95 90 120 0.6 Max 2.5 1 70 1 1 115 110 140 140 170 Unit V μA μA μA μA N EW PRODUCT TA = 25°C SOT25, MSOP-8-EP, SO-8 DFN2018-6 -40°C ≤ TA ≤ 85°C TA = 25°C -40°C ≤ TA ≤ 85°C RDS(ON) Switch on-resistance mΩ Enabled into short circuit, CL=22μF VIN= 5V, VOUT= 4.0V, CL=120μF, -40°C ≤ TA ≤85°C Output Current Slew rate (
