BAS16

BAS16/MMBD4148/MMBD914 SURFACE MOUNT SWITCHING DIODE Features · · · · Fast Switching Speed Surface Mount Package Ideally Suited for Automatic Insertion For General Purpose Switching Applications High Conductance TOP VIEW SOT-23 Dim A Min 0.37 1.20 2.30 0.89 0.45 1.78 2.80 0.013 0.903 0.45 0.85 0° Max 0.51 1.40 2.50 1.03 0.60 2.05 3.00 0.10 1.10 0.61 0.80 8° A B B C C D E G H Mechanical Data · · · · · · · Case: SOT-23, Molded Plastic Case material - UL Flammability Rating Classification 94V-0 Moisture sensitivity: Level 1 per J-STD-020A Terminals: Solderable per MIL-STD-202, Method 208 Polarity: See Diagram Marking: KA6, KA2, K5D (See Page 3) Weight: 0.008 grams (approx.) E D G H K J D L M J K L M a All Dimensions in mm Maximum Ratings @ TA = 25°C unless otherwise specified Characteristic Non-Repetitive Peak Reverse Voltage Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Forward Continuous Current (Note 1) Average Rectified Output Current (Note 1) Non-Repetitive Peak Forward Surge Current @ t = 1.0ms @ t = 1.0s Power Dissipation (Note 1) Thermal Resistance Junction to Ambient Air (Note 1) Operating and Storage Temperature Range Symbol VRM VRRM VRWM VR VR(RMS) IFM IO IFSM Pd RqJA Tj , TSTG Value 100 75 53 300 200 2.0 1.0 350 357 -65 to +150 Unit V V V mA mA A mW °C/W °C Electrical Characteristics Characteristic Reverse Breakdown Voltage (Note 2) Forward Voltage (Note 2) @ TA = 25°C unless otherwise specified Symbol V(BR)R VFM Min 75 ¾ Max ¾ 0.715 0.855 1.0 1.25 1.0 50 30 25 2.0 4.0 Unit V V mA mA mA nA pF ns Test Condition IR = 100mA IF = 1.0mA IF = 10mA IF = 50mA IF = 150mA VR = 75V VR = 75V, Tj = 150°C VR = 25V, Tj = 150°C VR = 20V VR = 0, f = 1.0MHz IF = IR = 10mA, Irr = 0.1 x IR, RL = 100W Leakage Current (Note 2) Total Capacitance Reverse Recovery Time IRM CT trr ¾ ¾ ¾ Notes: 2 1. Device mounted on glass epoxy PCB 1.6” x 1.6” x0.06”; mounting pad for the cathode lead min. 0.93in. 2. Short duration test pulse used to minimize self-heating effect. DS12003 Rev. 12 - 2 1 of 3 BAS16/MMBD4148/MMBD914 See Note 1 Pd, POWER DISSIPATION (mW) 400 IF, INSTANTANEOUS FORWARD CURRENT (mA) 500 1000 100 300 TA = +150°C 200 TA = +125°C 10 TA = +75°C TA = +25°C TA = -25°C 600 800 1000 1200 100 0 0 100 200 0.1 400 TA, AMBIENT TEMPERATURE, (°C) Fig. 1 Power Derating Curve VF, INSTANTANEOUS FORWARD VOLTAGE (mV) Fig. 2, Typical Forward Characteristics IF, INSTANTANEOUS REVERSE CURRENT (µA) 10 1 VR = 75V VR = 20V 0.1 0.01 0.001 0.0001 0 50 100 150 200 Tj, JUNCTION TEMPERATURE (°C) Fig. 3, Typical Reverse Characteristics DS12003 Rev. 12 - 2 2 of 3 BAS16/MMBD4148/MMBD914 Ordering Information Device BAS16-7 MMBD4148-7 MMBD914-7 Notes: (Note 3) Packaging SOT-23 Shipping 3000/Tape & Reel 3. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf. Marking Information XXX Date Code Key Year Code Month Code 1998 J Jan 1 Feb 2 1999 K March 3 XXX = Product Type Marking Code (See Page 1) YM = Date Code Marking Y = Year ex: N = 2002 M = Month ex: 9 = September 2000 L Apr 4 May 5 YM 2001 M Jun 6 2002 N Jul 7 Aug 8 2003 P Sep 9 Oct O 2004 R Nov N Dec D DS12003 Rev. 12 - 2 3 of 3 BAS16/MMBD4148/MMBD914
