BAS70-06T-7

BAS70T/ -04T/ -05T/ -06T SURFACE MOUNT SCHOTTKY BARRIER DIODE Features NEW PRODCUT · · · · · · · · · · · · Low Turn-on Voltage Fast Switching PN Junction Guard Ring for Transient and ESD Protection Ultra-Small Surface Mount Package B SOT-523 Dim A C TOP VIEW E G H K N L M BC Min 0.15 0.75 1.45 ¾ 0.90 1.50 0.00 0.60 0.10 0.10 0.45 0° Max 0.30 0.85 1.75 ¾ 1.10 1.70 0.10 0.80 0.30 0.20 0.65 8° Typ 0.22 0.80 1.60 0.50 1.00 1.60 0.05 0.75 0.22 0.12 0.50 ¾ A B C D G H J K L M N a Mechanical Data Case: SOT-523, Molded Plastic Case material - UL Flammability Rating 94V-0 Moisture sensitivity: Level 1 per J-STD-020A Terminals: Solderable per MIL-STD-202, Method 208 Polarity: See Diagrams Below Marking: See Diagrams Below & Page 2 Weight: 0.002 grams (approx.) Ordering Information, see Page 2 J D All Dimensions in mm BAS70T Marking: 7C BAS70-04T Marking: 7D BAS70-05T Marking: 7E BAS70-06T Marking: 7F Maximum Ratings and Electrical Characteristics, Single Diode @ TA = 25°C unless otherwise specified Characteristic Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Forward Continuous Current (Note 1) Non-Repetitive Peak Forward Surge Current @ tp < 1.0s Power Dissipation (Note 1) Thermal Resistance Junction to Ambient Air (Note 1) Operating Temperature Range Storage Temperature Range Symbol VRRM VRWM VR VR(RMS) IFM IFSM Pd RqJA Tj TSTG Value 70 49 70 100 150 833 -55 to +125 -65 to +150 Unit V V mA mA mW °C/W °C °C Electrical Ratings @ TA = 25°C unless otherwise specified Symbol V(BR)R VF IR CT Min 70 — ¾ ¾ — Max — 410 1000 100 2.0 5.0 Unit — mV nA pF ns Test Condition IR = 10mA tp
