BAS70-7-F

BAS70 /-04 /-05 /-06 SURFACE MOUNT SCHOTTKY BARRIER DIODE Please click here to visit our online spice models database. Features • • • • • Low Turn-on Voltage Fast Switching PN Junction Guard Ring for Transient and ESD Protection Lead, Halogen and Antimony Free, RoHS Compliant "Green" Device (Notes 3 and 4) Qualified to AEC-Q101 Standards for High Reliability Mechanical Data • • • • • • • • • Case: SOT-23 Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0 Moisture Sensitivity: Level 1 per J-STD-020D Terminals: Solderable per MIL-STD-202, Method 208 Lead Free Plating (Matte Tin Finish annealed over Alloy 42 leadframe). Polarity: See Diagrams Below Marking Information: See Page 2 Ordering Information: See Page 2 Weight: 0.008 grams (approximate) Top View BAS70 BAS70-04 BAS70-05 BAS70-06 Maximum Ratings @TA = 25°C unless otherwise specified Symbol VRRM VRWM VR VR(RMS) IFM IFSM Value 70 49 70 100 Unit V V mA mA Characteristic Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Maximum Forward Continuous Current (Note 1) Non-Repetitive Peak Forward Surge Current @ t ≤ 1.0s Thermal Characteristics Characteristic Power Dissipation (Note 1) Thermal Resistance Junction to Ambient Air (Note 1) Operating Junction Temperature Range Storage Temperature Range Symbol PD RθJA TJ TSTG Value 200 625 -55 to +125 -65 to +150 Unit mW °C/W °C °C Electrical Characteristics Characteristic Reverse Breakdown Voltage (Note 2) Forward Voltage Reverse Current (Note 2) Total Capacitance Reverse Recovery Time Notes: 1. 2. 3. 4. @TA = 25°C unless otherwise specified Symbol V(BR)R VF IR CT trr Min 70 — ⎯ ⎯ — Max — 410 1000 100 2.0 5.0 Unit V mV nA pF ns Test Condition IR = 10µA tp
