BAV16W

SPICE MODELS: BAV16W 1N4148W BAV16W/1N4148W SURFACE MOUNT FAST SWITCHING DIODE Features • • • • • Fast Switching Speed Surface Mount Package Ideally Suited for Automatic Insertion For General Purpose Switching Applications High Conductance Lead Free/RoHS Compliant (Note 2) Qualified to AEC-Q101 Standards for High Reliability H G D SOD-123 Dim A B C D E G A B Min 3.55 2.55 1.40 ⎯ 0.45 0.25 ⎯ 0° Max 3.85 2.85 1.70 1.35 0.65 ⎯ 0.10 8° • Mechanical Data • • • • • • • • • Case: SOD-123 Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0 Moisture Sensitivity: Level 1 per J-STD-020C Terminals: Solderable per MIL-STD-202, Method 208 Lead Free Plating (Matte Tin Finish annealed over Alloy 42 leadframe) Polarity: Cathode Band Marking: Date Code and Type Code, See Page 3 Type Code: T6, T4 Ordering Information: See Page 3 Weight: 0.01 grams (approximate) @TA = 25°C unless otherwise specified 0.55 Typical 0.11 Typical H J α C E All Dimensions in mm • Maximum Ratings Characteristic Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Forward Continuous Current Average Rectified Output Current Non-Repetitive Peak Forward Surge Current Power Dissipation (Note 1) Thermal Resistance Junction to Ambient Air (Note 1) Operating and Storage Temperature Range Notes: 1. Symbol VRRM VRWM VR VR(RMS) IFM IO @ t = 1.0μs @ t = 1.0s IFSM Pd RθJA Tj, TSTG Value 100 71 300 150 2.0 1.0 400 315 -65 to +150 Unit V V mA mA A mW °C/W °C Part mounted on FR-4 PC board with minimum recommended pad layout, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf. 2. No purposefully added lead. DS30086 Rev. 17 - 2 1 of 3 www.diodes.com BAV16W/1N4148W © Diodes Incorporated Electrical Characteristics Characteristic Reverse Breakdown Voltage (Note 3) Forward Voltage @TA = 25°C unless otherwise specified Symbol V(BR)R VFM Min 100 ⎯ Max ⎯ 0.715 0.855 1.0 1.25 1.0 50 30 25 2.0 4.0 Unit V V μA μA μA nA pF ns Test Condition IR = 1.0μA IF = 1.0mA IF = 10mA IF = 50mA IF = 150mA VR = 75V VR = 75V, Tj = 150°C VR = 25V, Tj = 150°C VR = 20V VR = 0, f = 1.0MHz IF = IR = 10mA, Irr = 0.1 x IR, RL = 100Ω Peak Reverse Current (Note 3) Total Capacitance Reverse Recovery Time IRM CT trr ⎯ ⎯ ⎯ Notes: 3. Short duration pulse test used to minimize self-heating effect. 500 PD, POWER DISSIPATION (mW) 400 300 200 100 0 0 25 50 75 100 125 150 TA, AMBIENT TEMPERATURE (°C) Fig. 1 Power Derating Curve DS30086 Rev. 17 - 2 2 of 3 www.diodes.com BAV16W/1N4148W © Diodes Incorporated Ordering Information Device BAV16W-7-F 1N4148W-7-F Notes: (Note 4) Packaging SOD-123 SOD-123 Shipping 3000/Tape & Reel 3000/Tape & Reel 4. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf. Marking Information XX XX = Product Type Marking Code (See Page 1) YM = Date Code Marking Y = Year ex: N = 2002 M = Month ex: 9 = September Date Code Key Year Code Month Code YM 2001 M Jan 1 2002 N Feb 2 2003 P Mar 3 2004 R Apr 4 2005 S May 5 2006 T Jun 6 2007 U Jul 7 2008 V Aug 8 2009 W Sep 9 2010 X Oct O 2011 Y Nov N 2012 Z Dec D IMPORTANT NOTICE Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes without further notice to any product herein. Diodes Incorporated does not assume any liability arising out of the application or use of any product described herein; neither does it convey any license under its patent rights, nor the rights of others. The user of products in such applications shall assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on our website, harmless against all damages. LIFE SUPPORT Diodes Incorporated products are not authorized for use as critical components in life support devices or systems without the expressed written approval of the President of Diodes Incorporated. DS30086 Rev. 17 - 2 3 of 3 www.diodes.com BAV16W/1N4148W © Diodes Incorporated
