BAV170

SPICE MODEL: BAV170 Lead-free BAV170 DUAL SURFACE MOUNT LOW LEAKAGE DIODE Features · · · · Surface Mount Package Ideally Suited for Automatic Insertion Very Low Leakage Current Lead Free/RoHS Compliant (Note 3) Qualified to AEC-Q101 Standards for High Reliability A SOT-23 Dim A B B TOP VIEW Min 0.37 1.20 2.30 0.89 0.45 1.78 2.80 0.013 0.903 0.45 0.085 0° Max 0.51 1.40 2.50 1.03 0.60 2.05 3.00 0.10 1.10 0.61 0.180 8° Mechanical Data · · · · · · · · Case: SOT-23 Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0 Moisture Sensitivity: Level 1 per J-STD-020C Terminals: Solderable per MIL-STD-202, Method 208 Lead Free Plating (Matte Tin Finish annealed over Alloy 42 leadframe). Polarity: See Diagram Marking: K51 & date code (see page 3) Weight: 0.008 grams (approximate) D J E D G H C C D E G H K L M J K L M a All Dimensions in mm Maximum Ratings @ TA = 25°C unless otherwise specified Characteristic Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Forward Continuous Current (Note 1) Repetitive Peak Forward Current Non-Repetitive Peak Forward Surge Current @ t = 1.0ms @ t = 1.0ms @ t = 1.0s Power Dissipation (Note 1) Thermal Resistance Junction to Ambient Air (Note 1) Operating and Storage Temperature Range Single Diode Double Diode Symbol VRRM VRWM VR VR(RMS) IFM IFRM IFSM Pd RqJA Tj , TSTG Value 85 60 215 125 500 4.0 1.0 0.5 250 500 -65 to +150 Unit V V mA mA A mW °C/W °C Electrical Characteristics @ TA = 25°C unless otherwise specified Characteristic Reverse Breakdown Voltage (Note 2) Forward Voltage Symbol V(BR)R VF Min 85 ¾ Typ ¾ ¾ Max ¾ 0.90 1.0 1.1 1.25 5.0 80 ¾ 3.0 Unit V V nA nA pF ms Test Condition IR = 100mA IF = 1.0mA IF = 10mA IF = 50mA IF = 150mA VR = 75V VR = 75V, Tj = 150°C VR = 0, f = 1.0MHz IF = IR = 10mA, Irr = 0.1 x IR, RL = 100W Leakage Current (Note 2) Total Capacitance Reverse Recovery Time Notes: IR CT trr ¾ ¾ ¾ ¾ 2 ¾ 1. Part mounted on FR-4 board with recommended pad layout, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf. 2. Short duration test pulse used to minimize self-heating effect. 3. No purposefully added lead. DS30234 Rev. 8 - 2 1 of 3 www.diodes.com BAV170 ã Diodes Incorporated 300 300 Device mounted on an FR4 printed-circuit board PD, POWER DISSIPATION (mW) IF, FORWARD CURRENT (mA) 250 250 200 200 150 150 Single diode loaded 100 100 50 50 0 Double diode loaded 0 0 25 50 75 100 125 150 0 50 100 150 200 TA, AMBIENT TEMPERATURE (°C) Fig. 1 Power Derating Curve TA, AMBIENT TEMPERATURE (° C) Fig. 2 Current Derating Curve IF, INSTANTANEOUS FORWARD CURRENT (mA) 1000 10 VR = 75V 100 10 IR, REVERSE CURRENT (nA) 1 1.0 0.1 0.01 0 1 2 VF, INSTANTANEOUS FORWARD VOLTAGE (V) Fig. 3 Typical Forward Characteristics 0.1 0 50 100 150 200 TA, AMBIENT TEMPERATURE (° C) Fig. 4 Typical Reverse Characteristics DS30234 Rev. 8 - 2 2 of 3 www.diodes.com BAV170 Ordering Information Device BAV170-7-F Notes: (Note 4) Packaging SOT-23 Shipping 3000/Tape & Reel 4. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf. Marking Information K51 K51 = Product Type Marking Code YM = Date Code Marking Y = Year ex: N = 2002 M = Month ex: 9 = September Date Code Key Year Code Month Code 2001 M Jan 1 2002 N Feb 2 2003 P March 3 2004 R Apr 4 2005 S May 5 2006 T Jun 6 2007 U Jul 7 2008 V Aug 8 2009 W Sep 9 2010 X Oct O 2011 Y Nov N 2012 Z Dec D IMPORTANT NOTICE Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes without further notice to any product herein. Diodes Incorporated does not assume any liability arising out of the application or use of any product described herein; neither does it convey any license under its patent rights, nor the rights of others. The user of products in such applications shall assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on our website, harmless against all damages. LIFE SUPPORT Diodes Incorporated products are not authorized for use as critical components in life support devices or systems without the expressed written approval of the President of Diodes Incorporated. DS30234 Rev. 8 - 2 3 of 3 www.diodes.com YM BAV170
