BAV99_10

BAV99 DUAL SURFACE MOUNT SWITCHING DIODE Please click here to visit our online spice models database. Features • • • • • • • Fast Switching Speed Surface Mount Package Ideally Suited for Automated Insertion For General Purpose Switching Applications High Conductance Lead Free/RoHS Compliant (Note 3) "Green" Device (Note 4) Qualified to AEC-Q101 Standards for High Reliability Mechanical Data • • • • • • • • SOT-23 Case: SOT-23 Case Material: Molded Plastic, “Green” Molding Compound (Note 4). UL Flammability Classification Rating 94V-0 Moisture Sensitivity: Level 1 per J-STD-020 Terminals: Matte Tin Finish annealed over Alloy 42 leadframe (Lead Free Plating). Solderable per MIL-STD-202, Method 208 Polarity: See Diagram Marking Information: See Page 2 Ordering Information: See Page 2 Weight: 0.008 grams (approximate) TOP VIEW TOP VIEW Internal Schematic Maximum Ratings @TA = 25°C unless otherwise specified Symbol VRM VRRM VRWM VR VR(RMS) IFM @ t = 1.0μs @ t = 1.0s IFSM Value 100 75 53 300 2.0 1.0 Unit V V V mA A Characteristic Non-Repetitive Peak Reverse Voltage Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Forward Continuous Current (Note 1) Non-Repetitive Peak Forward Surge Current Thermal Characteristics Characteristic Power Dissipation (Note 1) Thermal Resistance Junction to Ambient Air (Note 1) Operating and Storage Temperature Range Symbol PD RθJA TJ, TSTG Value 350 357 -65 to +150 Unit mW °C/W °C Electrical Characteristics @TA = 25°C unless otherwise specified Characteristic Reverse Breakdown Voltage (Note 2) Forward Voltage Symbol V(BR)R VF Min 75 ⎯ Max ⎯ 0.715 0.855 1.0 1.25 2.5 50 30 25 2.0 4.0 Unit V V μA μA μA nA pF ns Test Condition IR = 2.5μA IF = 1.0mA IF = 10mA IF = 50mA IF = 150mA VR = 75V VR = 75V, TJ = 150°C VR = 25V, TJ = 150°C VR = 20V VR = 0, f = 1.0MHz IF = IR = 10mA, Irr = 0.1 x IR, RL = 100Ω Reverse Current (Note 2) Total Capacitance Reverse Recovery Time Notes: 1. 2. 3. 4. IR CT trr ⎯ ⎯ ⎯ Part mounted on Polymide PC board with pad dimensions 1.13mm x 1.27mm. Short duration pulse test used to minimize self-heating effect. No purposefully added lead. Product manufactured with Data Code 9W (week 39, 2009) and newer are built with Green Molding Compound. Product manufactured prior to Date Code 9W are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants. BAV99 Document number: DS12007 Rev. 20 - 2 1 of 4 www.diodes.com April 2010 © Diodes Incorporated BAV99 IF, INSTANTANEOUS FORWARD CURRENT (A) IR, INSTANTANEOUS REVERSE CURRENT (nA) 1 10,000 1,000 0.1 100 10 0.01 1 0.001 1.0 0.5 0 1.5 VF, INSTANTANEOUS FORWARD VOLTAGE (V) Fig. 1 Forward Characteristics 0.1 0 20 40 60 80 100 VR, INSTANTANEOUS REVERSE VOLTAGE (V) Fig. 2 Typical Reverse Characteristics 2.0 1.8 CT, TOTAL CAPACITANCE (pF) 350 300 Pd, POWER DISSIPATION (mW) 250 200 150 100 50 R θJA = 357°C/W 1.6 1.4 1.2 1.0 0.8 0.6 0.4 0.2 0.0 0 10 30 40 20 VR, REVERSE VOLTAGE (V) Fig. 3 Typical Capacitance vs. Reverse Voltage 0 0 25 50 75 100 125 TA, AMBIENT TEMPERATURE (°C) Fig. 4 Power Derating Curve 150 Ordering Information Part Number BAV99-7-F BAV99-13-F Notes: (Note 5) Case SOT-23 SOT-23 Packaging 3,000/Tape & Reel 10,000/Tape & Reel 5. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf. Marking Information KJE = Product Type Marking Code YM = Date Code Marking Y = Year (ex: N = 2002) M = Month (ex: 9 = September) KJE Date Code Key Year Code Month Code 1998 J Jan 1 1999 K Feb 2 2000 L 2001 M Mar 3 2002 N Apr 4 YM 2003 P May 5 2004 R Jun 6 2005 S 2006 T Jul 7 2007 U Aug 8 2008 V Sep 9 2009 W Oct O 2010 X 2011 Y Nov N 2012 Z Dec D April 2010 BAV99 Document number: DS12007 Rev. 20 - 2 2 of 4 www.diodes.com © Diodes Incorporated BAV99 Package Outline Dimensions A BC H K D J F G L M K1 SOT-23 Dim Min Max Typ A 0.37 0.51 0.40 B 1.20 1.40 1.30 C 2.30 2.50 2.40 D 0.89 1.03 0.915 F 0.45 0.60 0.535 G 1.78 2.05 1.83 H 2.80 3.00 2.90 J 0.013 0.10 0.05 K 0.903 1.10 1.00 K1 0.400 L 0.45 0.61 0.55 M 0.085 0.18 0.11 0° 8° α All Dimensions in mm Suggested Pad Layout Y Z C Dimensions Value (in mm) Z 2.9 X 0.8 Y 0.9 C 2.0 E 1.35 X E BAV99 Document number: DS12007 Rev. 20 - 2 3 of 4 www.diodes.com April 2010 © Diodes Incorporated BAV99 IMPORTANT NOTICE DIODES INCORPORATED MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARDS TO THIS DOCUMENT, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE (AND THEIR EQUIVALENTS UNDER THE LAWS OF ANY JURISDICTION). Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes without further notice to this document and any product described herein. Diodes Incorporated does not assume any liability arising out of the application or use of this document or any product described herein; neither does Diodes Incorporated convey any license under its patent or trademark rights, nor the rights of others. Any Customer or user of this document or products described herein in such applications shall assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on Diodes Incorporated website, harmless against all damages. Diodes Incorporated does not warrant or accept any liability whatsoever in respect of any products purchased through unauthorized sales channel. Should Customers purchase or use Diodes Incorporated products for any unintended or unauthorized application, Customers shall indemnify and hold Diodes Incorporated and its representatives harmless against all claims, damages, expenses, and attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized application. Products described herein may be covered by one or more United States, international or foreign patents pending. Product names and markings noted herein may also be covered by one or more United States, international or foreign trademarks. LIFE SUPPORT Diodes Incorporated products are specifically not authorized for use as critical components in life support devices or systems without the express written approval of the Chief Executive Officer of Diodes Incorporated. As used herein: A. Life support devices or systems are devices or systems which: 1. are intended to implant into the body, or 2. support or sustain life and whose failure to perform when properly used in accordance with instructions for use provided in the labeling can be reasonably expected to result in significant injury to the user. B. A critical component is any component in a life support device or system whose failure to perform can be reasonably expected to cause the failure of the life support device or to affect its safety or effectiveness. Customers represent that they have all necessary expertise in the safety and regulatory ramifications of their life support devices or systems, and acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products and any use of Diodes Incorporated products in such safety-critical, life support devices or systems, notwithstanding any devices- or systems-related information or support that may be provided by Diodes Incorporated. Further, Customers must fully indemnify Diodes Incorporated and its representatives against any damages arising out of the use of Diodes Incorporated products in such safety-critical, life support devices or systems. Copyright © 2010, Diodes Incorporated www.diodes.com BAV99 Document number: DS12007 Rev. 20 - 2 4 of 4 www.diodes.com April 2010 © Diodes Incorporated
