MMDT2227

MMDT2227 COMPLEMENTARY NPN / PNP SMALL SIGNAL SURFACE MOUNT TRANSISTOR Features · · · · · Complementary Pair Epitaxial Planar Die Construction Ultra-Small Surface Mount Package One 2222A-Type NPN, One 2907A-Type PNP Ideal for Low Power Amplification and Switching SOT-363 A C2 B1 E1 Dim A B C D F H J M Min 0.10 1.15 2.00 0.30 1.80 ¾ 0.90 0.25 0.10 Max 0.30 1.35 2.20 0.40 2.20 0.10 1.00 0.40 0.25 KXX E2 B2 C1 BC Mechanical Data · · · · Case: SOT-363, Molded Plastic Terminals: Solderable per MIL-STD-202, Method 208 Terminal Connections: See Diagram Marking: K27 Weight: 0.006 grams (approx.) 0.65 Nominal H K K L M J D F L All Dimensions in mm Note: E1, B1, and C1 = PNP2907A Section, E2, B2, and C2 = NPN2222A Section. Type marking indicates orientation. Maximum Ratings, NPN2222A Section Characteristic Collector-Base Voltage Collector-Emitter Voltage Emitter-Base Voltage Collector Current - Continuous (Note 1) Power Dissipation (Note 1) Thermal Resistance, Junction to Ambient (Note 1) Operating and Storage and Temperature Range @ TA = 25°C unless otherwise specified Symbol VCBO VCEO VEBO IC Pd RqJA Tj, TSTG NPN2222A 75 40 6.0 600 200 625 -55 to +150 Unit V V V mA mW K/W °C Maximum Ratings, PNP2907A Section Characteristic Collector-Base Voltage Collector-Emitter Voltage Emitter-Base Voltage Collector Current - Continuous (Note 1) Power Dissipation (Note 1) Thermal Resistance, Junction to Ambient (Note 1) Operating and Storage and Temperature Range Note: @ TA = 25°C unless otherwise specified Symbol VCBO VCEO VEBO IC Pd RqJA Tj, TSTG PNP2907A -60 -60 -5.0 -600 200 625 -55 to +150 Unit V V V mA mW K/W °C 1. Valid provided that terminals are kept at ambient temperature. 2. Pulse test: Pulse width £ 300ms, duty cycle £ 2%. DS30122 Rev. B-2 1 of 4 MMDT2227 Electrical Characteristics, NPN2222A Section Characteristic OFF CHARACTERISTICS (Note 2) Collector-Base Breakdown Voltage Collector-Emitter Breakdown Voltage Emitter-Base Breakdown Voltage Collector Cutoff Current Collector Cutoff Current Emitter Cutoff Current Base Cutoff Current ON CHARACTERISTICS (Note 2) V(BR)CBO V(BR)CEO V(BR)EBO ICBO ICEX IEBO IBL Symbol @ TA = 25°C unless otherwise specified Min 75 40 6.0 ¾ ¾ ¾ ¾ 35 50 75 100 40 50 35 ¾ 0.6 ¾ ¾ — 300 ¾ Max ¾ ¾ ¾ 10 10 10 20 ¾ ¾ ¾ 300 ¾ ¾ ¾ 0.3 1.0 1.2 2.0 8 25 ¾ 4.0 Unit V V V nA mA nA nA nA Test Condition IC = 10mA, IE = 0 IC = 10mA, IB = 0 IE = 10mA, IC = 0 VCB = 60V, IE = 0 VCB = 60V, IE = 0, TA = 150°C VCE = 60V, VEB(OFF) = 3.0V VEB = 3.0V, IC = 0 VCE = 60V, VEB(OFF) = 3.0V IC = 100mA, VCE = 10V IC = 1.0mA, VCE = 10V IC = 10mA, VCE = 10V IC = 150mA, VCE = 10V IC = 500mA, VCE = 10V IC = 10mA, VCE = 10V, TA = -55°C IC = 150mA, VCE = 1.0V IC = 150mA, IB = 15mA IC = 500mA, IB = 50mA IC = 150mA, IB = 15mA IC = 500mA, IB = 50mA VCB = 10V, f = 1.0MHz, IE = 0 VEB = 0.5V, f = 1.0MHz, IC = 0 VCE = 20V, IC = 20mA, f = 100MHz VCE = 10V, IC = 100mA, RS = 1.0kW, f = 1.0kHz VCC = 30V, IC = 150mA, VBE(off) = - 0.5V, IB1 = 15mA DC Current Gain hFE ¾ Collector-Emitter Saturation Voltage Base- Emitter Saturation Voltage SMALL SIGNAL CHARACTERISTICS Output Capacitance Input Capacitance Current Gain-Bandwidth Product Noise Figure SWITCHING CHARACTERISTICS Delay Time Rise Time Note: VCE(SAT) VBE(SAT) V V Cobo Cibo fT NF pF pF MHz dB td tr ¾ ¾ 10 25 ns ns 1. Valid provided that terminals are kept at ambient temperature. 2. Pulse test: Pulse width £ 300ms, duty cycle £ 2%. DS30122 Rev. B-2 2 of 4 MMDT2227 Electrical Characteristics, PNP2907A Section Characteristic OFF CHARACTERISTICS (Note 2) Collector-Base Breakdown Voltage Collector-Emitter Breakdown Voltage Emitter-Base Breakdown Voltage Collector Cutoff Current Collector Cutoff Current Base Cutoff Current ON CHARACTERISTICS (Note 2) V(BR)CBO V(BR)CEO V(BR)EBO ICBO ICEX IBL Symbol @ TA = 25°C unless otherwise specified Min -60 -60 -5.0 ¾ ¾ ¾ 75 100 100 100 50 ¾ ¾ Max ¾ ¾ ¾ -10 -50 -50 ¾ ¾ ¾ 300 ¾ -0.4 -1.6 -1.3 -2.6 8.0 30 ¾ Unit V V V nA mA nA nA Test Condition IC = -10mA, IE = 0 IC = -10mA, IB = 0 IE = -10mA, IC = 0 VCB = -50V, IE = 0 VCB = -50V, IE = 0, TA = 125°C VCE = -30V, VEB(OFF) = -0.5V VCE = -30V, VEB(OFF) = -0.5V IC = -100µA, VCE = IC = -1.0mA, VCE = IC = -10mA, VCE = IC = -150mA, VCE = IC = -500mA, VCE = -10V -10V -10V -10V -10V DC Current Gain hFE ¾ Collector-Emitter Saturation Voltage Base- Emitter Saturation Voltage SMALL SIGNAL CHARACTERISTICS Output Capacitance Input Capacitance Current Gain-Bandwidth Product SWITCHING CHARACTERISTICS Turn-On Time Delay Time Rise Time Note: VCE(SAT) VBE(SAT) V V IC = -150mA, IB = -15mA IC = -500mA, IB = -50mA IC = 150mA, IB = 15mA IC = 500mA, IB = 50mA VCB = -10V, f = 1.0MHz, IE = 0 VEB = -2.0V, f = 1.0MHz, IC = 0 VCE = -20V, IC = -50mA, f = 100MHz IC = -150mA, VCC = -30V, IB1= -15mA VCC = -30V, IC = -150mA, IB1 = -15mA Cobo Cibo fT ¾ — 200 pF pF MHz ton td tr ¾ ¾ ¾ 45 10 40 ns ns ns 1. Valid provided that terminals are kept at ambient temperature. 2. Pulse test: Pulse width £ 300ms, duty cycle £ 2%. DS30122 Rev. B-2 3 of 4 MMDT2227 VCE COLLECTOR-EMITTER VOLTAGE (V) 30 20 10 1.6 1.4 1.2 1.0 0.8 0.6 0.4 0.2 0 0.001 IC = 1mA IC = 10mA IC = 100mA IC = 30mA IC = 300mA Cibo CAPACITANCE (pF) 5.0 Cobo 1.0 0.1 1.0 10 50 0.01 0.1 1 10 100 REVERSE VOLTS (V) Fig. 1 (2222A) Capacitances (Typical) IB BASE CURRENT (mA) Fig. 4 (2907A) Typical Collector Saturation Region 30 20 VCE COLLECTOR-EMITTER VOLTAGE (V) 1.6 1.4 1.2 1.0 0.8 0.6 0.4 0.2 0 0.001 IC = 1mA IC = 10mA IC = 100mA IC = 30mA IC = 300mA C, CAPACITANCE (pF) Cibo 10 5.0 Cobo 1.0 -0.1 -1.0 -10 -30 0.01 0.1 1 10 100 REVERSE VOLTS (V) Fig. 3 (2907A) Capacitances (Typical) IB BASE CURRENT (mA) Fig. 4 (2907A) Typical Collector Saturation Region DS30122 Rev. B-2 4 of 4 MMDT2227
