SBR1U40LP

SBR1U40LP 1.0A SBR® SUPER BARRIER RECTIFIER Features • • • • • • • Ultra Low Forward Voltage Drop Excellent High Temperature Stability Patented Super Barrier Rectifier Technology Soft, Fast Switching Capability 150ºC Operating Junction Temperature Lead Free By Design, RoHS Compliant (Note 1) “Green” Molding Compound (No Br, Sb) Mechanical Data • • • • • • • • Case: DFN1411-3 Case Material: Molded Plastic, “Green” Molding Compound. UL Flammability Classification Rating 94V-0 Moisture Sensitivity: Level 1 per J-STD-020C Terminal Connections: See Diagram Terminals: Finish - Matte Tin annealed over Copper lead frame. Solderable per MIL-STD-202, Method 208 Marking Information: See Page 3 Ordering Information: See Page 3 Weight: TBD grams (approximate) 2 1 3 N EW PRODUCT Top View Bottom View Top View Internal Schematic Maximum Ratings @TA = 25°C unless otherwise specified Single phase, half wave, 60Hz, resistive or inductive load. For capacitance load, derate current by 20%. Characteristic Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Average Rectified Output Current (See Figure 1) Symbol VRRM VRWM VRM VR(RMS) IO Value 40 28 1.0 Unit V V A Thermal Characteristics Characteristic Maximum Thermal Resistance Thermal Resistance Junction to Ambient (Note 2) Operating and Storage Temperature Range Symbol RθJA Tj, TSTG Value 190 -65 to +150 Unit ºC/W ºC Electrical Characteristics Characteristic Reverse Breakdown Voltage (Note 3) @TA = 25°C unless otherwise specified Symbol V(BR)R Min 40 Typ 0.39 0.46 0.34 0.43 Max 0.42 0.49 0.37 0.47 50 100 Unit V Test Condition IR = 100μA IF = 0.5A, Tj = 25ºC IF = 1.0A, Tj = 25ºC IF = 0.5A, Tj = 125ºC IF = 1.0A, Tj = 125ºC VR = 20V, Tj = 25ºC VR = 40V, Tj = 25ºC Forward Voltage Drop VF V Leakage Current (Note 3) Notes: IR μA 1. No purposefully added lead. 2. Device mounted on Polymide substrate 1” x 1”, 2oz. Copper double sided PCB board. 3. Short duration pulse test used to minimize self-heating effect. SBR is a registered trademark of Diodes Incorporated. SBR1U40LP Document number: DS31108 Rev. 4 - 2 1 of 3 www.diodes.com January 2008 © Diodes Incorporated SBR1U40LP IF, INSTANTANEOUS FORWARD CURRENT (A) 0.7 0.6 PD, POWER DISSIPATION (W) 0.5 0.4 0.3 0.2 0.1 0 0 0.5 1 1.5 IF(AV), AVERAGE FORWARD CURRENT (A) Fig. 1 Forward Power Dissipation 1 TA = 150°C 0.1 TA = 125°C N EW PRODUCT 0.01 TA = 85°C TA = 25°C 0.001 TA = -55°C 0.0001 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 VF, INSTANTANEOUS FORWARD VOLTAGE (V) Fig. 2 Typical Forward Characteristics 10,000 IR, INSTANTANEOUS REVERSE CURRENT(uA) 1,000 TA = 150°C T A = 125°C 10,000 1,000 C, CAPACITANCE (pF) f = 1MHz 100 TA = 85°C 10 100 1 TA = 25°C 10 0.1 0.01 0 5 10 15 20 25 30 35 40 VR, INSTANTANEOUS REVERSE VOLTAGE (V) Fig. 3 Typical Reverse Characteristics TA, DERATED AMBIENT TEMPERATURE (°C) 1 0.1 1 10 VR, DC REVERSE VOLTAGE (V) 100 1.6 IF(AV), AVERAGE FORWARD CURRENT (A) 1.4 1.2 1.0 0.8 0.6 0.4 0.2 0 25 Note 2 150 125 100 75 50 25 0 50 75 100 125 150 TA, AMBIENT TEMPERATURE (°C) Fig. 5 Forward Current Derating Curve 175 0 10 20 30 VR, DC REVERSE VOLTAGE (V) Fig. 6 Operating Temperature Derating 40 SBR is a registered trademark of Diodes Incorporated. SBR1U40LP Document number: DS31108 Rev. 4 - 2 2 of 3 www.diodes.com January 2008 © Diodes Incorporated SBR1U40LP Ordering Information Part Number SBR1U40LP-7 Notes: (Note 4) Case DFN1411-3 Packaging 5000/Tape & Reel 4. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf. Marking Information N EW PRODUCT D4 Date Code Key Year Code Month Code D4 = Product Type Marking Code YM = Date Code Marking Y = Year ex: U = 2007 M = Month (ex: 9 = September) 2010 X May 5 Jun 6 2011 Y Jul 7 2012 Z Aug 8 2013 A Sep 9 Oct O 2014 B Nov N 2015 C Dec D 2007 U Jan 1 Feb 2 2008 V Mar 3 2009 W Apr 4 Package Outline Dimensions G YM H DFN1411-3 Dim Min Max Typ A 1.35 1.48 1.40 B 1.05 1.18 1.10 C 0.65 0.85 0.75 D ⎯ ⎯ 0.125 E ⎯ ⎯ 0.25 F ⎯ ⎯ 0.175 G 0.47 0.53 0.50 H 0 0.05 0.02 K 0.25 0.35 0.30 L 0.22 0.33 0.275 M ⎯ ⎯ 0.55 N ⎯ ⎯ 0.20 All Dimensions in mm Suggested Pad Layout C X2 X1 G2 X Y Z G1 Dimensions Z G1 G2 X X1 X2 Y C Value (in mm) 1.38 0.15 0.15 0.95 0.75 0.40 0.75 0.76 IMPORTANT NOTICE Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes without further notice to any product herein. Diodes Incorporated does not assume any liability arising out of the application or use of any product described herein; neither does it convey any license under its patent rights, nor the rights of others. The user of products in such applications shall assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on our website, harmless against all damages. LIFE SUPPORT Diodes Incorporated products are not authorized for use as critical components in life support devices or systems without the expressed written approval of the President of Diodes Incorporated. SBR is a registered trademark of Diodes Incorporated. SBR1U40LP Document number: DS31108 Rev. 4 - 2 3 of 3 www.diodes.com January 2008 © Diodes Incorporated
