SD101A

SPICE MODELS: SD101A SD101B SD101C SD101A - SD101C SCHOTTKY BARRIER DIODE Features • • • • • Low Forward Voltage Drop Guard Ring Construction for Transient Protection Low Reverse Recovery Time Low Reverse Capacitance Lead Free Finish, RoHS Compliant (Note 2) Mechanical Data • • • • • • • • Case: DO-35 Case Material: Glass Moisture Sensitivity: Level 1 per J-STD-020C Leads: Solderable per MIL-STD-202, Method 208 Terminals: Finish ⎯ Matte Tin. Solderable per MIL-STD-202, Method 208 Polarity: Cathode Band Marking Information: See Page 2 Ordering Information: See Page 2 Weight: 0.13 grams (approximate) @TA = 25°C unless otherwise specified Symbol VRRM VRWM VR VR(RMS) IFM @ t ≤ 1.0s @ t = 10μs IFSM Pd RθJA Tj, TSTG SD101A 60 42 SD101B 50 35 15 50 2.0 400 375 -65 to +175 SD101C 40 28 Unit V V mA mA A mW °C/W °C DO-35 Dim A B C D Min 25.40 ⎯ ⎯ ⎯ Max ⎯ 4.00 0.60 2.00 All Dimensions in mm • Maximum Ratings Characteristic Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Forward Continuous Current (Note 1) Non-Repetitive Peak Forward Surge Current Power Dissipation (Note 1) Thermal Resistance, Junction to Ambient Air (Note 1) Operating and Storage Temperature Range Electrical Characteristics Characteristic Maximum Forward Voltage Drop @TA = 25°C unless otherwise specified Symbol SD101A SD101B SD101C SD101A SD101B SD101C SD101A SD101B SD101C SD101A SD101B SD101C Min Max 0.41 0.40 0.39 1.00 0.95 0.90 200 2.0 2.1 2.2 1.0 Unit Test Condition IF = 1.0mA IF = 1.0mA IF = 1.0mA IF = 15mA IF = 15mA IF = 15mA VR = 50V VR = 40V VR = 30V VR = 0V, f = 1.0MHz IF = IR = 5.0mA, Irr = 0.1 x IR, RL = 100Ω VFM ⎯ V Maximum Peak Reverse Current IRM ⎯ ⎯ ⎯ nA Total Capacitance CT trr pF ns Reverse Recovery Time Notes: 1. 2. Valid provided that leads are kept at ambient temperature. EC Directive 2002/95/EC (RoHS) revision 13.2.2003. Glass and high temperature solder exemptions applied where applicable, see EU Directive Annex Notes 5 and 7. DS11008 Rev. 13 - 2 1 of 2 www.diodes.com SD101A - SD101C © Diodes Incorporated Ordering Information (Note 3) Device SD101A-A SD101A-T SD101B-A SD101B-T SD101C-A SD101C-T Notes: 3. Packaging DO-35 DO-35 DO-35 DO-35 DO-35 DO-35 Shipping 10K/Ammo Pack 10K/Tape & Reel, 13-inch 10K/Ammo Pack 10K/Tape & Reel, 13-inch 10K/Ammo Pack 10K/Tape & Reel, 13-inch For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02008.pdf. IMPORTANT NOTICE Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes without further notice to any product herein. Diodes Incorporated does not assume any liability arising out of the application or use of any product described herein; neither does it convey any license under its patent rights, nor the rights of others. The user of products in such applications shall assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on our website, harmless against all damages. LIFE SUPPORT Diodes Incorporated products are not authorized for use as critical components in life support devices or systems without the expressed written approval of the President of Diodes Incorporated. DS11008 Rev. 13 - 2 2 of 2 www.diodes.com SD101A - SD101C © Diodes Incorporated
