SD101AW

SPICE MODELS: SD101AW SD101BW SD101CW SD101AW - SD101CW SCHOTTKY BARRIER SWITCHING DIODE Features • • • • • Low Forward Voltage Drop Guard Ring Construction for Transient Protection Negligible Reverse Recovery Time Very Low Reverse Capacitance Lead Free/RoHS Compliant (Note 3) SOD-123 Dim A B C D E G H J α Min 3.55 2.55 1.40 — 0.45 0.25 Max 3.85 2.85 1.70 1.35 0.65 — Mechanical Data • • • • • • • • Case: SOD-123 Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0 Moisture Sensitivity: Level 1 per J-STD-020C Leads: Solderable per MIL-STD-202, Method 208 Lead Free Plating (Matte Tin Finish annealed over Alloy 42 leadframe) Polarity: Cathode Band Marking: Date Code & Type Code, See Page 3 Type Codes: SD101AW S1 or SK SD101BW S2 or SK SD101CW S3 or SK Ordering Information: See Page 3 Weight: 0.01 grams (approximate) @TA = 25°C unless otherwise specified Symbol VRRM VRWM VR VR(RMS) IFM @ t ≤ 1.0s @ t = 10μs IFSM Pd RθJA Tj, TSTG SD101AW 60 42 SD101BW 50 35 15 50 2.0 400 300 -65 to +125 0.55 Typical 0.11 Typical — 0° 0.10 8° All Dimensions in mm • • Maximum Ratings Characteristic Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Forward Continuous Current (Note 1) Non-Repetitive Peak Forward Surge Current SD101CW 40 28 Unit V V mA mA A mW °C/W °C Power Dissipation (Note 1) Thermal Resistance, Junction to Ambient Air (Note 1) Operating and Storage Temperature Range Electrical Characteristics Characteristic Reverse Breakdown Voltage (Note 2) @TA = 25°C unless otherwise specified Symbol SD101AW SD101BW SD101CW SD101AW SD101BW SD101CW SD101AW SD101BW SD101CW SD101AW SD101BW SD101CW SD101AW SD101BW SD101CW V(BR)R Min 60 50 40 Max ⎯ 0.41 0.40 0.39 1.00 0.95 0.90 200 2.0 2.1 2.2 1.0 Unit V Test Condition IR = 10μA IR = 10μA IR = 10μA IF = 1.0mA IF = 1.0mA IF = 1.0mA IF = 15mA IF = 15mA IF = 15mA VR = 50V VR = 40V VR = 30V VR = 0V, f = 1.0MHz IF = IR = 5.0mA, Irr = 0.1 x IR, RL = 100Ω Forward Voltage Drop VFM ⎯ V Peak Reverse Current (Note 2) IRM ⎯ ⎯ ⎯ nA Total Capacitance CT trr pF ns Reverse Recovery Time Notes: 1. 2. 3. Part mounted on FR-4 board with recommended pad layout, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf. Short duration pulse test used to minimize self-heating effect. No purposefully added lead. DS11012 Rev. 17 - 2 1 of 3 www.diodes.com SD101AW-SD101CW © Diodes Incorporated DS11012 Rev. 17 - 2 2 of 3 www.diodes.com SD101AW-SD101CW © Diodes Incorporated Ordering Information (Note 4) Device SD101xW-7-F SD101xW-13-F Notes: 4. Packaging SOD-123 SOD-123 Shipping 3000/Tape and Reel 10,000/Tape and Reel For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf. Marking Information XX = Product Type Marking Code, See Page 1 YM = Date Code Marking Y = Year (ex: T = 2006) M = Month (ex: 9 = September) Date Code Key Year 1998 Code J Month Code 1999 K 2000 L Jan 1 2001 M Feb 2 2002 N Mar 3 2003 P Apr 4 2004 R May 5 2005 S Jun 6 2006 T Jul 7 2007 U Aug 8 2008 V 2009 W Sep 9 2010 X Oct O 2011 Y Nov N 2012 Z Dec D IMPORTANT NOTICE Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes without further notice to any product herein. Diodes Incorporated does not assume any liability arising out of the application or use of any product described herein; neither does it convey any license under its patent rights, nor the rights of others. The user of products in such applications shall assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on our website, harmless against all damages. LIFE SUPPORT Diodes Incorporated products are not authorized for use as critical components in life support devices or systems without the expressed written approval of the President of Diodes Incorporated. DS11012 Rev. 17 - 2 3 of 3 www.diodes.com SD101AW-SD101CW © Diodes Incorporated
