ECS-.327-CDX-0746

Low Profile 4.1 x 1.5 mm Footprint Extended Temp. Range RoHS Compliant ECS-.327-CDX-0746 SMD TUNING FORK CRYSTAL The miniature ECS-.327-CDX-0746 is a very compact SMD Tuning Fork Crystal. The 4.1 x 1.5 x 0.9 mm ceramic package is ideal for today's SMD manufacturing environment. OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS PARAMETERS Frequency Frequency Tolerance Load Capacitance Drive Level Equivalent Series Resistance Turnover Temperature Temperature Coefficient Shunt Capacitance First Year Aging Operating Temperature Storage Temperature Insulation Resistance Co +25°C ±3°C Topr Tstg @ 100V DC -40 -55 500M DL R1 +20 -0.028 +25 -0.034 1.05 ±3 +85 +125 CONDITIONS FO @ +25°C 12.5 0.1 1.0 70K +30 -0.04 °C ppm/°C² pF ppm °C °C ECS-.327-CDX-0746 MIN TYP 32.768 ± 20 MAX UNITS KHz ppm pF μW TOP, BOTTOM, SIDE VIEWS & LAND PATTERN Figure 3) Parabolic Temp Curve Figure 1) Top and Side View Figure 2) Bottom View and Suggested Land PART NUMBER: ECS-.327-CDX-0746 1105 South Ridgeview Road Olathe, KS 66062 Phone: 913.782.7787 Fax: 913.782.6991 www.ecsxtal.com
