5 x 7 Footprint 2 Pole Filter Tape & Reel Packaging
ECS-96SMF
SMD CRYSTAL FILTER
21.4 MHz
The ECS-96SMF 21.400 MHz Miniature SMD Monolithic Crystal Filters offer a narrow bandwidth and a 2 pole response in a 5 x 7 package.
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PART NUMBER *
CENTER FREQUENCY Fo MHz PASSBAND MIN. dB KHz ATTENUATION STOPBAND RIPPLE GUARANTEED MAX. MAX. MIN. dB KHz dB KHz dB LOSS MAX. dB TERMINATING IMPEDANCE Ω//pF OPERATING TEMPERATURE °C NO. OF POLES
ECS-96SMF21A7.5 ECS-96SMF21A15 ECS-96SMF21A20 ECS-96SMF21A30
21.400 21.400 21.400 21.400
3 3 3 3
± 3.75 ± 7.5 ± 10 ± 15
20 18 10 15
± 18.0 ± 25.0 ± 30.0 ± 45.0
70 70 70 70
-910 -910 -910 -910
1.0 1.0 1.0 1.0
2.0 2.0 2.0 2.0
850//6.0 1500//1.5 1800//1.0 2000//0.5
-30 ~ +80 -30 ~ +80 -30 ~ +80 -30 ~ +80
2 2 2 2
PACKAGE DIMENSIONS (mm)
PIN CONNECTIONS #1 #2 #3 #4 #5 #6 In/Out Ground Ground Out/In
Ground
Ground
1105 South Ridgeview Road
Olathe, KS 66062
Phone: 913.782.7787
Fax: 913.782.6991
www.ecsxtal.com
