ECS-PEC25-1000-B

Low Voltage PECL 7 x 5 mm Footprint Low Jitter Pb Free/RoHS Compliant ECS-PEC25/PEC33 SMD PECL OSCILLATOR ECS-PEC25 (2.5V) and ECS-PECS33 (3.3V) miniature SMD PECL oscillators. Ideal for low jitter applications. OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS ECS-PEC25 (+2.5V) ECS-PEC33 (+3.3V) PARAMETERS Frequency Range Operating Temperature Storage Temperature Supply Voltage Frequency Stability * Input Current Stand-by Current Output Symmetry Rise and Fall Times "0" level "1" level Output Load Disable delay time Enable/Startup time RMS Jitter Aging CONDITIONS MIN 40.0 0 -40 -50 +2.375 TYP MAX MIN TYP MAX 300.0 +70 +85 +125 +3.465 ± 100 ± 50 ± 25 90 30 45/55 1 +1.745 UNITS MHz °C °C °C VDC ppm ppm ppm mA µA % ns VDC VDC ns ms ps ppm Standard Extended (N Option) VDD Option A Option B Option C Pin 1 open or VIH Pin 1 = VIL @ 50% VDD level 20% VDD to 80% level VOL VOH 50Ω into VDD -2V +2.5 300.0 40.0 +70 0 +85 -40 +125 -50 +2.625 +3.135 ± 100 ± 50 ± 25 90 30 40/60 1 +1.195 +2.215 +3.3 +1.415 12 KHz to 20 MHz band 200 10 1 ±5 200 10 1 ±5 DIMENSIONS (mm) Pin Connections Pin #1 Pin #2 Pin #3 Pin #4 Pin #5 Pin #6 Tri-State N.C. Ground Output C-Output VDD Tri-State Control Voltage Pad 1 Open VIH 70% VDD Min VIL 30% VDD Max Pad 4 & 5 Oscillation Oscillation No Oscillation Figure 1) Top, Side and Bottom views Figure 2) Suggested Land Pattern Note: Internal crystal oscillation to be halted (Pin #1=VIL) PART NUMBERING GUIDE: Example ECS-PEC33-1000-B-N ECS Series Frequency Abbreviation 1000 = 100.000 MHz See Frequency Abbreviations (Pg 2) Stability Temperature Blank = 0 ~ +70°C M = -20 ~ +70°C N = -40 ~ +85°C Fax: 913.782.6991 www.ecsxtal.com PEC25 = +2.5V PEC33 = +3.3V A = ± 100 ppm B = ± 50 ppm C = ± 25 ppm 1105 South Ridgeview Road Olathe, KS 66062 Phone: 913.782.7787 ECS-PEC25/PEC33 SMD PECL OSCILLATOR Frequency Abbreviations FREQUENCY MHz 100.000 106.250 125.000 155.520 156.250 CODE 1000 1062.5 1250 1555.2 1562.5 Package Data Item Lid Base Sealing Terminal Plating RoHS Description Metal Ceramic Seam Tungsten (metalized) Gold/Nickel (Surface)/(Under) Compliant (Pb Free) 1105 South Ridgeview Road Olathe, KS 66062 Phone: 913.782.7787 Fax: 913.782.6991 www.ecsxtal.com
