VC-TX0-30SM

VC-TX0-30SM SERIES TEMPERATURE COMPENSATED OSCILLATOR The VC-TXO-30SM is a TCXO (Temperature Compensated Crystal Oscillator) featuring very tight stability over a wide temperature range. The miniature SMD ceramic package measures 5 x 7 x 2.0 mm. The voltage control feature has a frequency control range of ±5 ppm. The low profile package is ideal for wireless communications applications. FEATURES • Highly stable output • Voltage Control function • 5 x 7 mm Footprint • RoHS Compliant PART NUMBERING GUIDE “EXAMPLE” SERIES VC-TXO-30SM – FREQUENCY 128 – STABILITY/TEMPERATURE OPTION B Sample Part Number: VC-TXO-30SM-128-B, 128=12.8 MHz, B= ±2.0 PPM -20 +75˚C STANDARD FREQUENCIES 12.60, 12.80, 13.00, 14.40, 14.85, 16.80 19.20, 19.44, 19.68 & 19.80 MHZ OPERATING CONDITIONS/ELECTRICAL CHARACTERISTICS PARAMETERS FREQUENCY RANGE FREQUENCY TOLERANCE (OPTION A) (OPTION B) CONDITIONS TYPICAL @+25 ˚ ± 2 ˚ C OPER. TEMP. -10 ~ +60 ˚ C OPER. TEMP. -20 ~ +75 ˚ C OPER. TEMP. -20 ~ +75 ˚ C OPER. TEMP. -30 ~ +80 ˚ C +3V ±5% 10K Ω ±10%//10 pF ±10% First Year @ +25 ˚ C +3.0V DC Nominal 10K Ω ±10%//10 pF ±10% Clipped Sine Wave (DC-Cut) 10K Ω ±10%//10 pF ±10% +1.5 VDC ± 1V Positive Slope -120 dBc/Hz @ 1 KHz offset VC-TXO-30SM MIN 12.600 -0.5 -2.0 -2.0 -2.5 -2.5 -0.2 -0.3 -1.0 -40 +2.85 0.8 ±5.0 0.5 MAX 19.800 +0.5 +2.0 +2.0 +2.5 +2.5 +0.2 +0.3 +1.0 +85 +3.15 2.0 UNITS MHz PPM PPM PPM PPM PPM PPM PPM PPM ˚C V DC mA Vp-p PPM V dBc FREQ. STABILITY/TEMP. (OPTION C) (OPTION D) SUPPLY VOLTAGE CHANGE LOAD CHANGE AGING STORAGE TEMPERATURE SUPPLY VOLTAGE CURRENT CONSUMPTION OUTPUT VOLTAGE OUTPUT LOAD FREQUENCY CONTROL CONTROL VOLTAGE SSB PHASE NOISE HARMONIC DISTORTION Ultrasonic or Dip cleaning not to be used. Preliminary outline drawing. Consult factory for latest revision. (Rev. 1/03). 2.5 -3.0 PACKAGE DIMENSIONS (mm) 7.0 ± 0.2 #4 #3 #1 #2 VC-TX0-30SM PIN CONNECTIONS #1 V CONTROL #2 GND #3 OUTPUT #4 V CC 2.0 Max. 5.0 ± 0.2 1.6 1.4 3.68 1.4 0.9 3.0 0.9 4.3 5.1 1.3 Figure 1) VC-TX0-30SM – Top, Side and Bottom views Figure 2) Land Pattern ECS, INC. INTERNATIONAL 1105 S. RIDGEVIEW, OLATHE, KS 66062 • 913-782-7787 • 800-237-1041 • FAX 913-782-6991 • WWW.ECSXTAL.COM SMD TCXO 56 SMD TCXO
