VC-TXO-35SM

VC-TXO-35SM SERIES VC-TCXO The VC-TXO-35SM is a VC (Voltage Controlled) TCXO (Temperature Compensated Crystal Oscillator) featuring very tight stability over a wide temperature range. The small subminiature SMD ceramic package measures 3.2 x 5.0 x 1.5 mm. The voltage control has a tuning range of ± 5 ppm minimum. The low profile package is ideal for wireless communications applications. FEATURES • Highly stable output • Wide temperature • Voltage control function • Small footprint • Tape and Reel (1,000 pcs.) • PbFree/RoHS Compliant PART NUMBERING GUIDE S ERIES VC-TXO-35SM – FREQUENCY 128 – STABILITY / TEMPERATURE OPTION B Sample Part Number: VC-TXO35SM-128-B, 128=12.8 MHz, B=±2.5 ppm -30 to +75˚C STANDARD FREQUENCIES 13.000, 14.400, 16.800 AND 19.440 MHz OPERATING CONDITIONS/ELECTRICAL CHARACTERISTICS PARAMETERS FREQUENCY RANGE (OPTION A) (OPTION B) CONDITIONS OPER. OPER. OPER. OPER. TEMP. -20 ~ +75˚C TEMP. -30 ~ +75˚C TEMP. -20 ~ +75˚C TEMP. -30 ~ +80˚C +3.0 V ±5% 10k Ω ±10%//10pF ±10% Per Year @ +25˚C ± 3˚C MIN 12.000 V C-TXO-3SM (5V) TYP FREQUENCY STABILITY/TEMP (OPTION C) (OPTION D) SUPPLY VOLTAGE CHANGE LOAD CHANGE AGING STORAGE TEMPERATURE SUPPLY VOLTAGE INPUT CURRENT OUTPUT VOLTAGE OUTPUT LOAD FREQUENCY CONTROL RANGE CONTROL VOLTAGE +3.0 V DC Nominal Without Load Clipped sine wave (DC-Cut) 10k Ω ±10%//10pF ±10% +1.5 V DC ± 1V Positive Slope -40 +2.85 0.8 ±9 +0.5 +3.0 MAX 26.000 ±1.5 ±2.5 ±2.5 ±2.5 ±0.3 ±0.2 ±1 +85 +3.15 1.5 UNITS MHz PPM PPM PPM PPM PPM PPM PPM ˚C V DC mA Vp-p PPM V +1.5 ±15 +2.5 PACKAGE DIMENSIONS (mm) #4 #3 #1 #2 3.2 ±0.15 #1 #2 .07 #4 1.6 #3 3.2 1.5 max. 0.8 1.0 2.6 5.0 ±0.15 PAD CONNECTIONS #1 VCONTROL #2 GND #3 OUTPUT #4 VCC 4.0 Figure 1) VC-TXO-35SM Top, Side and Bottom views Figure 2) Land Pattern ECS, INC. INTERNATIONAL 1105 S. RIDGEVIEW, OLATHE, KS 66062 • 913-782-7787 • 800-237-1041 • FAX 913-782-6991 • WWW.ECSXTAL.COM OSCILLATORS 57 OSCILLATORS 1.2
