B682-60

Edal SERIES B682 Silicon Bridge Rectifier DIM. A B C D E F G H I J K INCHES MIN. MAX. 0.688 0.728 1.12 1.13 0.53 0.57 0.618 0.658 0.20 0.21 0618 0.658 0.030 0.134 0.248 0.252 0.826 0.905 0.09 0.10 0.28 0.31 MILLIMETERS MIN. MAX. 17.5 18.5 28.4 28.7 13.5 14.5 15.7 16.7 5.1 5.3 15.7 16.7 0.76 0.86 6.3 6.4 21.0 23.0 2.4 2.6 7.30 7.90 PART NUMBER B682-5 B682-10 B682-20 B682-30 B682-40 B682-50 PIV/LEG 50 100 200 300 400 500 PART NUMBER B682-60 B682-70 B682-80 B682-100 B682-120 PIV/LEG 600 700 800 1000 1200 ELECTRICAL RATINGS MAXIMUM FORWARD CURRENT SINGLE PHASE, FULL WAVE @ 50o C MAXIMUM SINGLE CYCLE SURGE CURRENT (AMPS) MAXIMUM FORWARD VOLTAGE DROP @ 25o C Io AMPS (FULL WAVE) V VOLTS (PER SECTION) MAXIMUM REVERSE CURRENT @ PIV @ 25o C THERMAL RESISTANCE, JUNCTION TO CASE @ RATED LOAD MAXIMUM JUNCTION TEMPERATURE RECOGNIZED UNDER UL FILE # E57830 25.0 AMPS 300 AMPS 12.5 1.1 10.0 uA 1.85o C o C/W 175o C (203) 467-2591 TEL (203) 469-5928 FAX Email: Info@ edal.com Internet:http://www.edal.com EDAL industries, inc. 51 Commerce St. East Haven, CT 06512
