SG-8002DC

Crystal oscillator PROGRAMMABLE HIGH-FREQUENCY CRYSTAL OSCILLATOR SG-8002DB/ DC series • • • • Wide frequency output by PLL technology. Quick delivery of samples and short lead mass production time. Excellent shock resistance and environmental capability. Output enable function (OE) and stand-by function (ST) can be used for low current consumption applications. • Pin compatible with full size and half size. 8002 PROM Writer available to purchase.(Type:PRW-8000A3-M01) Please contact EPSON or local sales representative. Actual size SG-8002DB SG-8002DC Specifications (characteristics) Item Output frequency range Power source voltage Temperature range Max. supply voltage Operating voltage Storage temperature Operating temperature Symbol f0 VDD-GND VDD TSTG TOPR TSOL ∆f/f0 Iop IOE IST tw/t VOH VOL N CL VIH VIL tTLH tTHL tOSC fa S.R. PT/ST PH/SH Specifications PC/SC Remarks 1.0000 MHz to 125.0000 MHz -0.5V to +7.0V 5.0V±0.5V -55˚C to +125˚C -20˚C to +70˚C (-40˚C to +85˚C) 3.3 ± 0.3V -40˚C to +85˚C 3.0V ±0.3V: f0 ≤ 66.7MHz(PC/SC) Refer to page 4."Frequency range" Soldering condition Frequency stability Current consumption Output disable current Standby current Duty High output voltage Low output voltage Output load condition (fan out) Twice at under 260˚C within 10 sec. or under 230˚C within 3 min. B: ±50ppm C: ± 100ppm M: ±100ppm(-40˚C to +85˚C) -20˚C to +70˚C No load condition, Max. frequency range OE=GND(PT, PH, PC) ST=GND(ST, SH, SC) C-MOS load: 1/2VDD level TTL load: 1.4V level IOH=-16mA(PT /ST, PH /SH),-8mA(PC /SC) IOL= 16mA(PT /ST, PH /SH), 8mA(PC /SC) 45mA max. 30mA max. 50µA max. 28mA max. 16mA max. — 40% to 60% TTL C-MOS Output enable/disable input voltage Output rise time Output fall time C-MOS level TTL level C-MOS level TTL level 40% to 60% — VDD -0.4V min. 0.4V max. 5TTL max. — 15pF max. 25pF max. 15pF max. 2.0V min. 0.7 × VDD min. 0.8V max. 0.2 × VDD max. — 4ns max. 4ns max. — — 4ns max. 4ns max. — 10ms max. ±5ppm/year max. ±20ppm max. Max. frequency and max. operating voltage range ST, OE terminal C-MOS load: 20%→80% VDD TTL load: 0.4V→2.4V C-MOS load: 80%→20% VDD TTL load: 2.4V→0.4V _ Oscillation start up time Aging Shock resistance Note: Time at minimum operating voltage to be 0 sec. Ta= 25˚C, VDD = 5.0V/3.3V(PC/SC) Three drops on a hard board from 75 cm or excitation test with 3000G x 0.3ms x 1/2sine wave in 3 directions • Please contact us for inquiries about operating temperature(-40˚C to +85˚C), usable frequencies, duty and output load conditions. Checking possible by the Frequency Checking Program. http://www.epson.co.jp/CRYSTAL/ (Unit: mm) External dimensions SG-8002DB series 19.8max. # 14 #8 (Unit: mm) 16.0000 C 2PH EPSON 9357B #1 #7 6.36 7.62 #1 #4 6.6 No. Pin terminal 1 OE or ST 7 GND 8 OUT 14 VDD SG-8002DC series 13.7max. #8 #5 EPSON 100.0000 C 9357B 2PH No. Pin terminal 1 OE or ST 4 GND 5 OUT 8 VDD 7.62 2.54min. 5.3max. 5.3max. 0.2min. 2.54min. 90 to 105˚ 15.24 7.62 0.2min. 90 to 105˚ 0.25 (Wired-or connection & Jitter specification, please refer to page 13.) (Wired-or connection & Jitter specification, please refer to page 13.) 35 THE CRYSTALMASTER ENERGY SAVING EPSON EPSON offers effective savings to its customers through a wide range of electronic devices, such as semiconductors, liquid crystal display (LCD) modules, and crystal devices. These savings are achieved through a sophisticated melding of three different efficiency technologies. Power saving technology provides low power consumption at low voltages. Energy Saving Space saving technology provides further reductions in product size and weight Power Saving through super-precise processing and high-density assembly technology. Space Saving Time saving technology shortens the time required for design and development Time Saving on the customer side and shortens delivery times. Our concept of Energy Saving technology conserves resources by blending the essence of these three efficiency technologies. The essence of these technologies is represented in each of the products that we provide to our customers. In the industrial sector, leading priorities include measures to counter the greenhouse effect by reducing CO2, measures to preserve the global environment, and the development of energyefficient products. Environmental problems are of global concern, and although the contribution of energyResource saving technology developed by Saving EPSON may appear insignificant, we seek to contribute to the development of energy-saving products by our customers through the utilization of our electronic devices. EPSON is committed to the conservation of energy, both for the sake of people and of the planet on which we live. SEIKO EPSON CORP. QUARTZ DEVICE DIVISION acquired ISO9001 and ISO14001 certification by B.V.Q. I. (Bureau Veritas Quality International) . ISO9001 in October, 1992. ISO14001 in November,1997. NOTICE No part of this material may be reproduced or duplicated in any form or by any means without the written permission of Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any liability of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or circuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such as, medical products. Moreover, no license to any intellectual property rights is granted by implication or otherwise, and there is no representation or warranty that anything made in accordance with this material will be free from any patent or copyright infringement of a third party. This material of portions there may contain technology or the subject relating to strategic products under the control of the Foreign Exchange and Foreign Trade Control Law of Japan and may require an export license from the Ministry of International Trade and Industry or other approval from another government agency.
