CA-301

C rystal Crystal unit Epson Toyocom Product Number (please contact us) Q21CA3011xxxx00 M Hz RANGE CRYSTAL UNIT CYLINDER CA - 301 • Frequency range • Thickness • Overtone order • Applications : : : : 4 MHz to 64 MHz φ 3.1 mm Max. Fundamental 3rd overtone (30 MHz to 64 MHz) For Clock of integrated circuit Actual size Specifications (characteristics) Item Nominal frequency range Temperature range Operating temperature Storage temperature Symbol f_nom T _stg T _use Specification 4.000 MHz to 29.999 MHz 30.000 MHz to 64.000 MHz -40 ° C to +85 ° C -20 ° C to +70 ° C 10 µW to 100 µW ±30 × 10-6(Under 5.5 MHz:±50 × 10-6, ±100 × 10-6 ) +25 ° C Under 5.5 MHz: ±50 × 10-6 -10 ° C to +60 ° C Over 5.5 MHz: ±30 × 10-6 -20 ° C to +70 ° C Fundamental: 10 pF to ∞ . Load capacitance CL Please specify Overtone: 5 pF to ∞ Motional resistance (ESR) R1 As per below table -20 ° C to +70 ° C, DL=100 µW Frequency aging f_age ±5 × 10-6 / year Max. +25 ° C, First year *1 4.0 MHz ≤ f_nom < 5 .5 MHz : See “Available frequencies from 4.0 MHz to less than 5.5 MHz”. 8.0 MHz < f_nom < 8 .2 MHz: Unavailable. *2 26.000 MHz ≤ f_nom
