CA-301_10

Crystal unit Epson Toyocom Product Number (please contact us) Q21CA3011xxxx00 MHz RANGE CRYSTAL UNIT CYLINDER CA - 301 •Frequency range •Thickness •Overtone order •Applications : : : : 4 MHz to 64 MHz φ3.1 mm Max. Fundamental 3rd overtone (30 MHz to 64 MHz) For Clock of integrated circuit Actual size Specifications (characteristics) Item Nominal frequency range Temperature range Operating temperature Level of drive Frequency tolerance (standard) Frequency versus temperature characteristics (standard) Storage temperature Symbol f_nom T_stg T_use DL f_tol Specification 4.000 MHz to 29.999 MHz 30.000 MHz to 64.000 MHz -40 °C to +85 °C -20 °C to +70 °C 10 μW to 100 μW -6 ±30 × 10 (Under 5.5 MHz:±50 × 10-6, ±100 × 10-6) +25 °C Under 5.5 MHz: ±50 × 10-6 -10 °C to +60 °C f_tem Over 5.5 MHz: ±30 × 10-6 -20 °C to +70 °C Fundamental: 10 pF to ∞. Load capacitance CL Please specify Overtone: 5 pF to ∞ Motional resistance (ESR) R1 As per below table -20 °C to +70 °C, DL=100 μW Frequency aging f_age ±5 × 10-6 / year Max. +25 °C, First year *1 4.0 MHz ≤ f_nom < 5.5 MHz : See “Available frequencies from 4.0 MHz to less than 5.5 MHz”. 8.0 MHz < f_nom < 8.2 MHz: Unavailable. *2 26.000 MHz ≤ f_nom
