Crystal unit
Epson Toyocom
Product Number (please contact us)
MHz RANGE CRYSTAL UNIT
MINIATURE SIZE LOW PROFILE SMD
FA-238V : Q22FA23V0xxxx00 FA-238 : Q22FA2380xxxx00 TSX-3225 : X1E000021xxxx00
FA - 238V / FA - 238 TSX - 3225
•Frequency range : • External dimensions : : •Overtone order : •Applications : : 12 MHz to 60 MHz(FA-238,FA-238V) 3.2 × 2.5 × 0.6 t (mm) ···TSX-3225 3.2 × 2.5 × 0.7 t (mm) ···FA-238V / FA-238 Fundamental Mobile phone, Bluetooth, W-LAN ISM band radio, Clock for MPU Actual size FA-238V/ FA-238 TSX-3225
Specifications (characteristics)
Item Nominal frequency range Temperature Storage temperature Range Operating temperature Level of drive Frequency tolerance Frequency versus temperature characteristics Load capacitance Motional resistance (ESR) Frequency aging Symbol f_nom T_stg T_use DL f_tol f_tem CL R1 f_age As per below table ±5 × 10-6 / year Max. For Clock FA-238V FA-238 12.000 MHz to 15.999 MHz 16.000 MHz to 60.000 MHz For RF Reference TSX-3225 16.000 MHz to 48.000 MHz Remarks Fundamental *1 For the out of standard specifications, please contact us for inquiries. Store as bare product after unpacking Recommended: 1 to 100 μW +25 °C For the out of standard specifications, please contact us for inquiries. *1 For the out of standard specifications, please contact us for inquiries. *1 For the out of standard specifications, please contact us for inquiries. -40 °C to +85 °C, DL = 100 μW +25 °C, First year
-40 °C to +125 °C -40 °C to +85 °C 200 μW Max. ±50 × 10-6 (standard), (±15 × 10-6 to ±50 × 10-6 is available) ±30 × 10-6/-20 °C to +70 °C 7 pF to ∞
±10 × 10-6
±10 × 10-6/-20 °C to +75 °C
As per below table ±1 × 10-6 / year Max.*2
*1 FA-238: For over 40 MHz, only the standard specification applies. -6 *2 40 MHz ≤ f_nom : ±2 × 10 / year Max.
Motional resistance (ESR)
(FA-238V / FA-238) Frequency 12.0 MHz ≤ f_nom ≤ 13.0 MHz 13.0 MHz < f_nom < 20.0 MHz 20.0 MHz ≤ f_nom < 25.0 MHz 25.0 MHz ≤ f_nom < 30.0 MHz 30.0 MHz ≤ f_nom ≤ 60.0 MHz Motional resistance 100 Ω Max. 80 Ω Max. 60 Ω Max. 50 Ω Max. 40 Ω Max. (TSX-3225) Frequency 16.0 MHz ≤ f_nom < 21.0 MHz 21.0 MHz ≤ f_nom ≤ 48.0 MHz Motional resistance 60 Ω Max. 40 Ω Max.
External dimensions
#4
(Unit:mm) FA-238
#4 #3 #4 2.5±0.1
FA-238V
#3
TSX-3225
#3 2.5±0.15
1200M V66RA
#1 3.2±0.1
2000M E66RA
#1 3.2±0.1
2.5±0.1
Internal connection (TOP VIEW) #4 #3 #1 #2
Marking
#1
#2 0.7 Max.
#2 0.7 Max.
3.2±0.15
#2 0.6 Max.
#2 and #4 are connected to the cover. (Please connect to ground)
1.3 #1 #2 #1
1.2 #2 #1
1.0 #2
0.7
0.9
C 0.3 Min.
0.7
#4
0.85
#3
#4
0.8
0.9
#3
#4
1.0
#3
0.8 0.7
Footprint (Recommended)
FA-238V 2.4 FA-238 2.2 TSX-3225 2.2
(Unit:mm)
1.9 1.2 1.4
1.6 1.2 1.4
1.6 1.15 1.4
http://www.epsontoyocom.co.jp
