SG-210

C rystal Crystal oscillator Epson Toyocom Product Number (please contact us) Q33210Bx0xxxx00 CRYSTAL OSCILLATOR SPXO SG - 210 series • Frequency range : • Supply voltage : • Current consumption : 2 MHz to 60 MHz 1.5 V Typ. / 1.8 V Typ. / 2.5 V Typ. / 3.3 V Typ. 0.9 mA Typ. (SEB 1.8 V No load condition 48 MHz) • Function : Standby( ST ) Actual size • Thickness : 0.8 mm Typ. • Operation temperature : +105 ° C / +125 °C Specifications (characteristics) Item Output frequency range Supply voltage Storage Temperature temperature range Operating temperature Symbol SG-210SGB 2 MHz to 32 MHz 1.5 V Typ. 1.3 V to 1.7 V Specifications SG-210SEB SG-210SDB 2 MHz to 60 MHz 1.8 V Typ. 1.6 V to 2.2 V SG-210SCB 3.3 V Typ. 2.7 V to 3.6 V Remarks f0 VCC T_stg T_use 2.5 V Typ. 2.2 V to 3.0 V -40 ° C to +125 °C -40 ° C to +85 °C / -40 ° C to +105 °C / -40 ° C to +125 °C Store as bare product after unpacking Frequency tolerance f_tol – – 1.0 mA Max. – 0.3 µA Max. – 45 % to 55 % 40 % to 60 % – – Current consumption Stand-by current Symmetry High output voltage Low output voltage Output load condition (CMOS) Output enable / disable input voltage Rise time and Fall time Start-up time Frequency aging ICC I_std SYM VOH VOL L_CMOS VIH VIL -10 ° C to +60 ° C, f0 ≤ 32 MHz, VCC ±10%, except reflow drift. 6 B: ±50 × 10-6, C: ±100 × 10-20 ° C to +70 ° C L:±50 × 10-6,M:±100 × 10-6 -40 ° C to +85 ° C -6 -6 Y:±50 × 10 ,W:±100 × 10 -40 ° C to +105 ° C Z:±100 × 10-6,X:±150 × 10-6 -40 ° C to +125 ° C 1.6 mA Max. 2.4 mA Max. 3.0 mA Max. No load condition 2.0 mA Max 3.0 mA Max. 4.0 mA Max. No load condition +105 ° C,+125 ° C 0.5 µA Max. 1.0 µA Max. 1.0 µA Max. ST =GND 1.6 µA Max. 2.4 µA Max. 3.0 µA Max. ST =GND +105 ° C,+125 ° C 2 MHz≤f0≤16 MHz 45 % to 55 % 45 % to 55 % 45 % to 55 % 16 MHz
