8L00 Series/Spartan DIP Reed Relays ELAYS ECONOMY DIP REED RELAYS D IP N W! E The Coto 8L00 Spartan Series relays combine Coto quality and economy in the industry standard 14 pin molded DIP package. This series will cross to all competitive DIP packages and is ideal for telecom, security, and other general purpose applications. EATURES 8L00 SERIES FEATURES u u u u u Drop-in low cost replacement for industry standard DIP packages. Available in Form 1A, 1C, 2A and 1B packages and 5, 12, and 24 V coil designs. Molded thermoset body on integral lead frame design. Hermetically Sealed Contacts. Optional Electrostatic Shield and Coil Suppression Diode. Dimensions in Inches (Millimeters) Rhopoint Components Ltd Fax: +44 (0) 1883 712938 Phone: +44 (0) 1883 717988 web: www.rhopointcomponents.com e-mail: sales@rhopointcomponents.com 8L00 Series/Spartan DIP Reed Relays Model Number Parameters COIL SPECS. Nom. Coil Voltage Max. Coil Voltage Coil Resistance Operate Voltage Release Voltage CONTACT RATINGS Switching Voltage Switching Current Carry Current Contact Rating Life Expectancy-Typical Static Contact Resistance (max. init.) Dynamic Contact Resistance (max. init.) RELAY SPECIFICATIONS Insulation Resistance (minimum) Dielectric Strength (minimum) 1 8L01 Test Conditions Units VDC VDC Ω VDC - Max. VDC - Min. Volts Amps Amps Watts x 10 Ops. Ω Ω 6 8L02 2 Form A 8L21 1 Form B 8L41 1 Form C 1 Form A 5 6.5 3.8 0.5 12 15 24 32 5 6.5 3.8 0.5 12 15 24 32 5 6.5 3.8 0.5 12 15 24 32 5 6.5 3.8 0.5 12 15 24 32 +/- 10%, 25° C Must Operate by Must Release by Max DC/Peak AC Resist. Max DC/Peak AC Resist. Max DC/Peak AC Resist. Max DC/Peak AC Resist. Signal Level 1.0V,10mA 50mV, 10mA 0.5V, 50mA at 100 Hz, 1.5 msec 500 500 2150 9.6 19.2 1.0 2.0 200 500 2000 9.6 19.2 1.0 2.0 200 500 2000 9.6 19.2 1.0 2.0 200 500 2000 9.6 19.2 1.0 2.0 200 0.5 1.0 10 500 0.150 N/A 200 0.5 1.0 10 500 0.150 N/A 200 0.5 1.0 10 500 0.150 N/A 100 0.25 0.5 3 100 0.200 N/A Between all Isolated Pins at 100V, 25°C, 40% RH Between Contacts Contacts to Shield Contacts/Shield to Coil At Nominal Coil Voltage, 30 Hz Square Wave No Suppression Diode Suppression Ω VDC/peak AC VDC/peak AC VDC/peak AC msec. msec. msec. x 10 10 x 10 10 x 10 9 x 10 9 250 1500 1500 250 1500 1500 250 1500 1500 250 1500 1500 Operate Time - including bounce - Typical Release Time - Typical 0.5 0.5 1.0 0.5 0.5 1.0 0.5 0.5 1.0 1.0 1.0 1.5 Top View: Dot stamped on top of relay refers to pin #1 location Grid = .1"x.1" (2.54mm x 2.54mm) Notes: Molded Depression on top of relay refers to pin #1 location. Optional coil suppression diode across pins 2(+) and 6(-). Optional ES shield is tied to pins 9 and 13 Environmental Ratings Storage Temp: -35 °C to +100 °C; Operating Temp: -20 °C to + 85 °C The operate and release voltage and the coil resistance are specified at 25 °C. These values vary by approximately 0.4%/°C as the ambient temperature varies. Vibration: 20 G’s to 2000 Hz; Shock: 50 G’s Rhopoint Components Ltd Fax: +44 (0) 1883 712938 Phone: +44 (0) 1883 717988 web: www.rhopointcomponents.com e-mail: sales@rhopointcomponents.com
