BC56-1X

Kingbright Features l0.56 lLOW ® 14mm (0.56INCH) THREE DIGIT NUMERIC DISPLAYS BA56-11 BA56-12 BA56-13 BC56-11 BC56-12 BC56-13 Description The Bright Red source color devices are made with Gallium Phosphide Red Light Emitting Diode. The Green source color devices are made with Gallium Phosphide Green Light Emitting Diode. The High Efficiency Red source color devices are made with Gallium Arsenide Phosphide on Gallium Phosphide Orange Light Emitting Diode. The Yellow source color devices are made with Gallium Arsenide Phosphide on Gallium Phosphide Yellow Light Emitting Diode. The Super Bright Red source color devices are made with Gallium Aluminum Arsenide Red Light Emitting Diode. INCH DIGIT HEIGHT. CURRENT OPERATION. CHARACTER APPEARANCE. MOUNTING ON P.C. BOARDS OR SOCKETS. FOR LUMINOUS INTENSITY, RUGGED. lEXCELLENT lEASY lI.C. COMPATIBLE. lCATEGORIZED YELLOW AND GREEN CATEGORIZED FOR COLOR. lMECHANICALLY lSTANDARD : GRAY FACE, WHITE SEGMENT. Package Dimensions Interal Circuit Diagram 7-B56-1 Package Dimensions Interal Circuit Diagram Notes: 1. All dimensions are in millimeters (inches), Tolerance is ±0.25(0.01")unle ss otherwise noted. 2. Specifications are subjected to change whitout notice. Selection Guide Part No. BA56-11HWA BA56-12HWA BA56-13HWA BC56-11HWA BC56-12HWA BC56-13HWA BA56-11EWA BA56-12EWA BA56-13EWA BC56-11EWA BC56-12EWA BC56-13EWA BA56-11GWA BA56-12GWA BA56-13GWA BC56-11GWA BC56-12GWA BC56-13GWA BA56-11YWA BA56-12YWA BA56-13YWA BC56-11YWA BC56-12YWA BC56-13YWA BA56-11SRWA BA56-12SRWA BA56-13SRWA BC56-11SRWA BC56-12SRWA BC56-13SRWA Dice Iv (ucd) @ 10 mA Min. Max. Description Comomn Anode, Rt. Hand Decimal BRIGHT RED (GaP) 900 2200 Common Cathode, Rt. Hand Decimal Common Anode, Rt. Hand Decimal HIGH EFFICIENCY RED (GaAsP/GaP) 2200 9000 Common Cathode, Rt. Hand Decimal Common Anode, Rt. Hand Decimal GREEN (GaP) 2200 5600 Common Cathode, Rt. Hand Decimal Common Anode, Rt. Hand Decimal YELLOW (GaAsP/GaP) 2200 5600 Common Cathode, Rt. Hand Decimal Common Anode, Rt. Hand Decimal SUPER BRIGHT RED (GaAlAs) 5600 21000 Common Cathode, Rt. Hand Decimal 7-B56-2 Electrical / Optical Characteristics at TA=25°C Symbol Parameter Device Bright Red High Efficiency Red Green Yellow Super Bright Red Bright Red High Efficiency Red Green Yellow Super Bright Red Bright Red High Efficiency Red Green Yellow Super Bright Red Bright Red High Efficiency Red Green Yellow Super Bright Red All Typ. 700 625 565 590 660 45 45 30 35 20 40 12 45 10 95 2.0 2.0 2.2 2.1 1.85 10 Max. Units Test Conditions λpeak Peak Wavelength nm IF=20mA ∆λ1/2 Spectral Line Halfwidth nm IF=20mA C Capacitance pF VF=0V;f=1MHz vF Forward Voltage 2.5 2.5 2.5 2.5 2.5 V IF=20mA IR Reverse Current uA VR = 5V Absolute Maximum Ratings at TA=25°C Parameter Power dissipation DC Forward Current Peak Forward Current [1] Reverse Voltage Operating/Storage Temperature Lead Soldering Temperature [2] Notes: 1. 1/10 Duty Cycle, 0.1ms Pulse Width. 2. 4mm below package base. Bright Red 120 25 150 5 High Efficiency Red 105 30 150 5 Green 105 25 150 5 Yellow 105 30 150 5 Super Bright Red 100 30 150 5 Units mW mA mA V -40 ° C To +85 ° C 260 ° C For 5 Seconds 7-B56-3 Bright Red High Efficiency Red 7-B56-4 Green Yellow 7-B56-5 Super Bright Red 7-B56-6
