CO-TS7050

- 32- Temperature Compensated Crystal Oscillator ( TCXO / VC-TCXO ) H igh stability ■ Features ● ● ● ● ● CO-TS7050 , CO-TS7050V 10 to 26 MHz Low power consumption Supply voltage available brtween 2.7 to 5.0V Package : Metal lid + Ceramic base 7 .0×5.0×1.9mm ■ Electrical Performance Description Available Frequency Range Frequency Stability vs.Operating (25ﾟC ref.) Temperture Storage Temperture Supply Voltage Supply Current Supply Voltage Change Output Voltage Load Load Change Voltage Control Phase Noise Symbols F0 dFt/F Tsto Vcc Icc dFv Vo Zcr dFz dF/V PN CO-TS7050 CO-TS7050V 10.000 ∼ 26.000 MHz ±1.5ppm,±2.0ppm, ±2.5ppm ( -30 to +75ﾟC ) ±2.5ppm, ±3.0ppm ( -40 to +85ﾟC ) -40 to +85ﾟC +2.7 to 5.0V 2.0 mA max ±0.2 ppm / Vcc±5% 0.8Vp-p ( Clipped sine wave ) 10 KΩ//10pF ±0.2 ppm ( 10KΩ±10% // 10pF±10% ) ±8ppm,±10ppm,±15ppm/+1.5±1.0V -135dBc / Hz typ.(1.0KHz) ■ Environmental Characteristics Description Aging (First Year) Shock Vibration Solderability Humidity Symbols Specification ±1.0 ppm max/year Test: 3 times free drop onto concrete board from 150cm heigh Result: ±1.0 ppm max Test: Frequency 5-500Hz, Amplitude 1.5mm, Test time 4cycles/XYZ axis Result: ±1.0 ppm max Test: More than 95%, at 235±5ﾟC for 3 sec Test: 90 to 95% relative humidity at +60±3ﾟC for 1000 hours Result: ±1.0 ppm max ■ Outline Drawing & Suggested Pad 7.0±0.2 TERMINAL CONECTION TCXO VCTCXO Vcont GND OUTPUT Vcc 5. 0±0. 2 #1 MA RKING GND GND OUTPUT Vcc #2 #3 #4 1 .9 m ax 1.5 #1 # 2 4 −(1 .0 ) # 4 #3 1.2 5.08 4−(1.4) ■ Suggested Pad (Top View) T L TE CH ICA LIN C .,L N L K O TD. 4 .2
