HS-7002

PICMG Bus 800MHz FSB DDR GPIO CRT/LVDS Panel TV-Out Dual Giga LAN Audio Serial ATA ATA/33/66/100 RS-232/422/485 4 COM PC/104 IrDA USB2.0 WDT H/W Monitor HS-7002 DDR Socket 82865GV Single Single Board Computer 800MHz FSB Pentium 4 PICMG Bus SBC with Serial ATA, CRT/LVDS Panel, Audio, Dual Giga LAN & TV-Out 82801EB SATA IDE Battery Parallel FDD MIC In/Audio Out Internal USB COM 2 COM 1 Dual RJ-45 82562EZ or 82547EI 82540 External USB Internal USB RS-422/485 PGA 478 CH7017A 4-pin ATX Power In 5-pin ATX Power In Fan LVDS Panel Fan TV-Out 20-pin ATX Power In PC/104 IT8888 Award BIOS COM 3 Fan CRT PS/2 KB/MS COM 4 Features ● PGA 478 for Intel Pentium 4 CPU with Hyper-Threading Technology up to 3.2GHz ● Supports 400/533/800MHz FSB ● Two DDR sockets with a max. capacity of 2GB ● Intel 82865GV/82801EB system chipset ● Winbond W83627 super I/O chipset ● Intel 82865GV CRT display controller ● Intel 82562EZ 10/100 Based (or 82547EI 100/1000 Based) and Intel 82540 100/1000 Based LAN ● ● ● ● ● ● ● ● ● AC97 3D audio controller Supports Serial ATA controller Fast PCI ATA/33/66/100 IDE controller Four COM, seven USB2.0 connectors PC/104 Bus connector Supports Hardware Monitor Supports 8-bit General Purpose Input/Output Supports LVDS Panel interface (optional) Supports TV-Out function (optional) Specifications *CPU: PGA 478 for Intel Pentium 4 CPU with Hyper-Threading Technology up to 3.2GHz *Bus Interface: PICMG Bus *Front Side Bus: Supports 400/533/800MHz FSB *Memory: Two DDR sockets supporting DDR-266/333/400 up to 2GB *Chipset: Intel 82865GV/82801EB *I/O Chipset: Winbond W83627 *ISA Bridge: ITE IT8888 (16-bit) *VGA: Intel 82865GV with 1MB/8MB/16MB shared main memory supporting CRT display up to 1600 x 1200 at 32-bit colors at 60Hz *LVDS Panel: Supports LVDS interface (optional) *TV-Out: Supports PAL or NTSC TV systems (optional) *LAN: Intel 82562EZ 10/100 Based (or 82547EI 100/1000 Based) and Intel 82540 100/1000 Based LAN *Audio: AC97 3D audio controller *Serial ATA: Intel ICH5 controller and with two ports supporting transfer rate up to 150MB/sec. *IDE: Four IDE disk drives supporting ATA/33/66/100 and with transfer rates of 33/66/100MB/sec. *FDD: Supports up to two floppy disk drives *Parallel: One enhanced bi-directional parallel port supporting SPP/ECP/EPP *Serial Port: 16C550 UART-compatible RS-232/422/485 x 1 and RS-232 x 3 serial ports with 16-byte FIFO *PC/104: PC/104 Bus connector for 16-bit ISA Bus *IrDA: One IrDA TX/RX connector *USB: Seven USB2.0 connectors, six internal and one external *Keyboard/Mouse: PS/2 6-pin Mini DIN *BIOS: Award PnP Flash BIOS *Watchdog Timer: Software programmable time-out intervals from 1~256 sec. *CMOS: Battery backup *Power Connector: One 20-pin and one 4-pin ATX power connector *Temperature: 0~+60oC (operating) *Hardware Monitor: Winbond W83627 *Dimensions: 33.8(L) x 12.1(W) cm Ordering Guide ● HS-7002 800MHz FSB P4 SBC w/Serial ATA, CRT/LVDS, Audio, Dual G LAN, TV-Out, 4C/485, USB2.0, & Fan(251-0000020) ● HS-7002LLV 800MHz FSB P4 SBC w/Serial ATA, CRT/LVDS, Audio, 1GL1L, 2C, USB2.0, & Fan(251-0000020) ● HS-7002LV 800MHz FSB P4 SBC w/Serial ATA, CRT, Audio, LAN, 2C, USB2.0, & Fan(251-0000020) Accessory Options: 251-0000020 Height=3cm, CPU cooler for PGA 478 1.7~2.8GHz CPU 251-0000037 1U high, CPU cooler for PGA 478 1.7~2.4GHz CPU 251-0000035 2U high, CPU cooler for PGA 478 2.8~3.06GHz CPU or other high level CPU ISO 9001 Certification R 15F-6, No. 77, Hsin Tai Wu Road, Sec. 1, Hsichih, Taipei Hsien 221 Taiwan TEL: 886-2-26983333 FAX: 886-2-26983300 http://www.boser.com.tw / http://www.ipc.com.tw E-mail: webmaster@boser.com.tw / sales@boser.com.tw U.S.A TEL: +1 650 9673898 FAX: +1 650 4281172 U.K. TEL: +44 1543 466552 FAX: +44 1543 466553 Korea TEL: +82 2 32823999 FAX: +82 2 32823992 France TEL: +33 1 69061790 FAX: +33 1 69433732 India Germany TEL: +91 657 3107955 TEL: +49 221 954790 FAX: +91 657 2433941 FAX: +49 221 9547988 Italy TEL: +39 051 452042 FAX: +39 051 455046 Israel TEL: +972 3 9203456 FAX: +972 3 9203535 Finland TEL: +358 2 6203753 FAX: +358 2 6203770 ShangHai/BeiJing TEL: 021 51098750 FAX: 021 63456286
