LP-230-10

Flathead™ Low Profile Transformers Printed Circuit Mount SM For Low Power and Critical Height Applications Part No. LP-10-250 LP-10-600 LP-10-1200 LP-10-2400 LP-10-4800 LP-12-200 LP-12-450 LP-12-900 LP-12-1900 LP-12-3800 LP-16-150 LP-16-350 LP-16-700 LP-16-1500 LP-16-3000 LP-20-125 LP-20-300 LP-20-600 LP-20-1200 LP-20-2400 LP-24-100 LP-24-250 LP-24-500 LP-24-1000 LP-24-2000 LP-30-85 LP-30-200 LP-30-400 LP-30-800 LP-30-1600 LP-34-75 LP-34-170 LP-34-340 LP-34-700 LP-34-1400 LP-40-60 LP-40-150 LP-40-300 LP-40-600 LP-40-1200 LP-56-45 LP-56-100 LP-56-200 LP-56-425 LP-56-850 LP-88-28 LP-88-65 LP-88-130 LP-120-20 LP-120-50 LP-120-100 LP-230-10 LP-230-25 LP-230-50 VA (Size) 2 6 12 24 48 2 6 12 24 48 2 6 12 24 48 2 6 12 24 48 2 6 12 24 48 2 6 12 24 48 2 6 12 24 48 2 6 12 24 48 2 6 12 24 48 2 6 12 2 6 12 2 6 12 Secondary RMS Rating Series Parallel 10VCT @ 250mA 5V @ 500mA 10VCT @ 600mA 5V @ 1.2A 10VCT @ 1200mA 5V @ 2.4A 10VCT @ 2.40A 5V @ 4.80A 10VCT @ 4.80A 5V @ 9.60A 12.6VCT @ 200mA 6.3V @ 400mA 12.6VCT @ 450mA 6.3V @ 900mA 12.6VCT @ 900mA 6.3V @ 1.8A 12.6VCT @ 1.90A 6.3V @ 3.80A 12.6VCT @ 3.80A 6.3V @ 7.60A 16VCT @ 150mA 8V @ 300mA 16VCT @ 350mA 8V @ 700mA 16VCT @ 700mA 8V @ 1.4A 16VCT @ 1.50A 8V @ 3.00A 16VCT @ 3.00A 8V @ 6.00A 20VCT @ 125mA 10V @ 250mA 20VCT @ 300mA 10V @ 600mA 20VCT @ 600mA 10V @ 1.2A 20VCT @ 1.20A 10V @ 2.40A 20VCT @ 2.40A 10V @ 4.80A 24VCT @ 100mA 12V @ 200mA 24VCT @ 250mA 12V @ 500mA 24VCT @ 500mA 12V @ 1A 24VCT @ 1.00A 12V @ 2.00A 24VCT @ 2.00A 12V @ 4.00A 30VCT @ 85mA 15V @ 170mA 30VCT @ 200mA 15V @ 400mA 30VCT @ 400mA 15V @ 800mA 30VCT @ 800mA 15V @ 1.60A 30VCT @ 1.60A 15V @ 3.20A 34VCT @ 75mA 17V @ 150mA 34VCT @ 170mA 17V @ 340mA 34VCT @ 340mA 17V @ 680mA 34VCT @ 700mA 17V @ 1.40A 34VCT @ 1.40A 17V @ 2.80A 40VCT @ 60mA 20V @ 120mA 40VCT @ 150mA 20V @ 300mA 40VCT @ 300mA 20V @ 600mA 40VCT @ 600mA 20V @ 1.20A 40VCT @ 1.20A 20V @ 2.40A 56VCT @ 45mA 28V @ 90mA 56VCT @ 100mA 28V @ 200mA 56VCT @ 200mA 28V @ 400mA 56VCT @ 425mA 28V @ 850mA 56VCT @ 850mA 28V @ 1.70A 88VCT @ 28mA 44V @ 56mA 88VCT @ 65mA 44V @ 130mA 88VCT @ 130mA 44V @ 260mA 120VCT @ 20mA 60V @ 40mA 120VCT @ 50mA 60V @ 100mA 120VCT @ 100mA 60V @ 200mA 230VCT @ 10mA 115V @ 20mA 230VCT @ 25mA 115V @ 50mA 230VCT @ 50mA 115V @ 100mA CV Signal’s LP transformers use hum-bucking (semi toroidal) construction that minimizes radiated magnetic fields. These transformers are ideal for critical low height pc board applications. General Specifications s Power – 2 VA to 48 VA s Dielectric Strength – 1500VRMS Hipot s Primaries – Dual primaries (115V/230V - 50/60 Hz) s Secondaries – Series or parallel secondaries s Electrostatic Shield – Not necessary, split bobbin construction s Magnetic Field – Reduced magnetic radiation s Height – .65 to 1.375 inches high s Insulation – Class B insulation (130°C) Agency Standards s UL recognized to UL 506 (File #E63829) s CSA certified to C22.2 #66 (File #LR 51265) VA (Size) 2 6 12 24 48 A 1.600˝ 40.6mm 1.600˝ 40.6mm 2.000˝ 50.8mm 1.900˝ 48.3mm 2.180˝ 55.4mm B 0.375˝ 9.5mm 0.375˝ 9.5mm 0.500˝ 12.7mm 0.600˝ 15.2mm 0.600˝ 15.2mm C 0.375˝ 9.5mm 0.375˝ 9.5mm 0.500˝ 12.7mm 0.530˝ 13.5mm 0.660˝ 16.8mm L 1.87˝ 47.5mm 1.87˝ 47.5mm 2.50˝ 63.5mm 2.87˝ 72.9mm 3.12˝ 79.2mm W 1.56˝ 39.6mm 1.56˝ 39.6mm 2.00˝ 50.8mm 2.25˝ 57.2mm 2.50˝ 63.5mm H 0.650˝ 16.5mm 0.850˝ 21.6mm 1.065˝ 27.1mm 1.250˝ 31.8mm 1.375˝ 34.9mm N – – – – – – 2.41˝ 61.2mm 2.62˝ 66.5mm D .041 x .020˝ 1.04 x 0.51mm .041 x .020˝ 1.04 x 0.51mm .041 x .020˝ 1.04 x 0.51mm .041(SQ pin) 1.04SQmm .041(SQ pin) 1.04SQmm P – – – Clearance Hole for #4 Screw Clearance Hole for #6 Screw Wgt 5 oz 0.14 kg 7 oz 0.20 kg 11 oz 0.31 kg 15 oz 0.43 kg 21 oz 0.60 kg Signal Transformer CALL: 516-239-5777 • FAX: (24hrs) 516-239-7208 500 Bayview Avenue, Inwood, New York 11096 Signal Catalog page 15
