7336-1

RF Wideband Transformer A compact SMD wideband transformer with excellent dielectric strength to meet North American and European standards for reinforced insulation. Meets safety codes: UL 1950 CSA C22.2 No.950 BSI & TUV EN 60950 7336-1 MECHANICAL (All dimensions in millimetres) SCHEMATIC 7336-1 ELECTRICAL SPECIFICATIONS @ 25˚C Insertion Loss (dB MAX) 50 - 100 MHz 7336 - 1 50/50 6 Frequency Response (dB MAX) 3 - 25 MHz 0.2 Dielectric Strength (VAC) 3000 ISSUE: P2 28/05/02 Part Number Impedance (Ω) 229 Colonnade Road, Ottawa, Ontario, Canada K2E 7K3 Tel: (613) 226-1626 Fax: (613) 226-7124 www.filtran.com An ISO 9001 Registered Company
