CT-522

Semitronics Description: The CT-522 is solid-state replacement for Mil-R39016/13 mechanical relay. Eliminating the need for life-cycle maintenance replacements. Solid-State Relays CT-522 Double Pole Double Throw Low Level to 2 Amperes 0.150 in. Terminal Spacing Features • • • Same Footprint as Mil-R-39016/13 Small Size High Reliability Pin X1 is identified by contrasting color bead. Table 1: Electrical Characteristics Limits Parameter Units Min Max Contact Ratings: Operating Voltage 200 V Leakage Current 50 uA Maximum Current 2 A Ton/Toff 3 mS NO Contact On State 1.5 V Voltage @ 2 Amps NC Contact On State 1.0 V Voltage @ 2 Amps Control Rating: Operating Voltage @ 28 VDC 35 mA A3 NC NO A2 X2 B3 NC NO B2 A1 X1 B1 Circuit Diagram Mechanical Dimensions SYMBOL A B C D E ∅F H INCHES MIN MAX 0 .610 0 .310 0 .320 0 .180 0.200 0 .145 0.155 0.018 0.022 0.190 0.200 Semitronics, 64 Commercial St. Freeport, NY 11520 Tel (516) 623-9400 / Fax (516) 623-6954 Pg. 1 of 1
